Split Core Current Transformer
Negotiable
MOQ: 200 Units (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Maxwel
Model Number:
MS1-812
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Zhejiang, China
Brand Name
Maxwel
Model Number
MS1-812
Usage
Current
Phase
Single
Coil Structure
Toroidal
Coil Number
Autotransformer
Specifications
Split Core Current TransformerIron Core Can be Easily Opened and Installed
IEC44-1, BS7626, VCE0414, VL94 standard approval
Split core current transformers, current transformer
• Small size and easy mounting
• Wide innner window, allowing clamping of big cables and bus bars
• Wide range of sizes to accommodate all the existing installations
• High accuracy and reliablility
Primary current: 100A-5000A
Secondary current: 5A, 1A
Standard approval: IEC44-1, BS7626, VDE0414, VL94
Maximun Voltage: 0.72/3KV
Frequency: 50/60Hz
Rated load: 1 VA-30VA
Class: 0.5, 1.0, 3.0
Short-time thermal current: 1th=100 x In
Rated security coefficient Fs<5
Popular in Russian, Germany, Greece, Italy, South Africa etc.
CE pass!
Quality guarantee!
Competive price!
| Model | Nominal current ratio | Burden VA | |
| Class:0.5 | Class:1 | ||
| VA | |||
| MS1-812 | 500 | 2.5 | 12 |
| 600 | 2.5 | 15 | |
| 750 | 2.5 | 17.5 | |
| 800 | 2.5 | 18 | |
| 1000 | 5 | 18 | |
| 1200 | 6 | 20 | |
| 1250 | 7.5 | 25 | |
| 1500 | 7.5 | 25 | |
