1X10W LEDs MINI Moving Head Beam
Key Features:
1.Physical Length: 14cm
Width: 11cm
Height:25cm
Weight: 1.8kg without accessories
2.Dynamic effects :Beam color wheel:13 color + open
Beam color temperature: CTO, 8000K
Electronic dimming: 0-100% linear dimming
Strobe and pulse effects: 1-12 times/second, flicker free
Speed color-wheel: rotation effect and random color
Electronic "shutter" effect: instant open and blackout
Pan:540°
Tilt:270°
Pan and tilt speed : Adjustable via on board control panel and DMX
7.0-100% smooth linear dimmer with flicker free
8.Built-programs with macro effects
9. Low noise and efficient FAN cooling system
Specifications:
| Input Voltage |
100-240v nominal, 50/60 Hz |
| Power consumption | 40W |
| Light source | white LEDs lamp |
Rated power | 40W |
| Lamp life | 50,000hours |
| Color Range | 16.7millions additive RGBW Colors |
| DMX channels | 6/10CH |
| Operation Mode | DMX512,master-slave and sound activated controllable or auto operation |
| Movement | Pan/Tilt 540°/270°,speed fine adjustable |
| Dimmer | 0-100% smooth linear dimmer with flicker free |
| Strobe | 20t/s with variable speed, Pre-programmed random strobe and pulse effects |
| Beam Angles | 8degree |
| Display | High definition blue LCD display |
| Housing | Composite plastic(IP20) |
| Work environment | 45°C max ambient temperature |
| Fixture Color | black |
| Control connection | 3-pin DMX |
| Dimension | 152(L)*265(W)*335(H)mm |
| Packing size | 260(L)*320(W)*335(H)mm |
N.W | 1.8KG |
| G.W | 2.5KG |
| IP | 20 |
DMX Channel
| CH | Function | Values | Description |
| 1 | Pan | 0-255 | PAN Movement |
| 2 | Pan Fine | 0-255 | Fine control of Pan movement 16Bit |
| 3 | Tilt | 0-255 | Tilt Movement |
| 4 | Tilt Fine | 0-255 | Fine control of Tilt movement 16Bit |
| 5 | Dimmer | 0-255 | 0-100%Linear dimmer from dark to bright |
| 6 | Strobe Mode | 0-15 | Empty |
| 16-95 | Normal speed strobe | ||
| 96-175 | From fast to slowly | ||
| 176-255 | From slowly to fast | ||
| 7 | Red | 0-255 | 0-100% red dimmer from dark to bright |
| 8 | Green | 0-255 | 0-100% green dimmer from dark to bright |
| 9 | Blue | 0-255 | 0-100% blue dimmer from dark to bright |
| 10 | White | 0-255 | 0-100% white dimmer from dark to bright |
| 11 | Colors Choice | 0-255 | Colors changing effect |
| 12 | Macros and Sound Control | 0-010 | CH1-CH11 Activated |
| 011-120 | Colors jumping | ||
| 121-180 | Colors fading | ||
| 181-244 | Colors mixing and strobe | ||
| 245-255 | Sound control | ||
| 13 | Macros Speed | 0-255 | Speed of macros(slow to fast) |
| 14 | PAN/TILT Speed | 0-255 | Speed control of PAN/TILT(fast to slow) |
| 15 | Reset | 0-244 | CH1-CH14 Activated |
| 245-255 | Reset after 3 seconds |
Photometric Data
Photometric Beam Angle Data 8°Beam Angle LUX *0.0929=FC
Trade Terms
| MOQ | 1pcs |
| Price term | EXW Or FOB |
| Shipping method | By DHL,UPS,Fedax if small order; And ship by sea or air if bulk order |
| Payment terms | T/T for small order, L/Cfor big order 30% for deposit,the balance 70% before shipment. |
| Sample time | 3-5 workdays after received the payment |
| Lead time | Usually within 2 weeks depend on the quantity after we received the deposit |
| Packing | Carton or Flight case(Flight case need to buy) |
| After sells service | within one year,if there is damage, we free Provide all accessories and services,Except for glass parts; After one year, we provide all the accessories, the parts cost only charge |
| Accept | OEM &ODM |
