Home > Products > E-Glass Needle Mat > 5mmx1000mmx30m E-Glass Fiber Needle Mat for Automobile and motorcycle exhaust system
5mmx1000mmx30m E-Glass Fiber Needle Mat for Automobile and motorcycle exhaust system
- 5 Ton / Tons per Month
- QINGDAO
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Technique: | Needle Mat | Dimensions: | 5mmx1000mmx30m | Mat Type: | Stitch Bonding Chop Mat |
Fiberglass Type: | E-Glass | Softness: | soft | Place of Origin: | Shandong, China |
Brand Name: | BAOYANGWOOL | Model Number: | BY-5 |
Product Description
Fiberglass needle mat is a kind of rational structure, performance, good filter material, with glass fiber as raw material, after combed with thorn for short cut glass fiber needle felt, felt with mechanical method between layers of glass fiber, glass fiber mat layer and mutual entanglement between fiber reinforced fiberglass cloth, fabric is strengthened and blanket made of nonwoven filter material.
Performance |
|
1,A non-incombustibility, good chemical resistance, is an excellent insulating material |
|
2,Absorbent small, high security of water, which can effectively prevent condensation |
|
3,The restoration of the high rate of compression, impact shock |
|
4,High porosity, and excellent sound-absorbing |
|
5,At a high temperature with low shrinkage, long service life |
|
6,Low conductivity, good insulation is a material |
|
7,The maximum operating temperature of 710 degrees E-type |
|
8,Post-processed into tubes, excellent wind resistance |
|
9,Sophie unique song of easy to cut, in favor of the installation |
|
10,Adhesives do not contain any |
|
11,Do not contain any harmful substances, non-perishable, in line with environmental standards |
|
Application |
|
1,Shipbuilding, steel, aluminum, petrochemical, power, chemical pipe insulation material |
|
2,Automobile and motorcycle exhaust system, hood, seats and other sound-absorbing insulation materials |
|
3,Architecture: roof, exterior walls, interior walls, floor insulation boards acoustic material |
|
4,Air-conditioning, household appliances of thermal insulation materials |
|
5,Molding thermoplastic materials can (GMT) and polypropylene sheet substrate enhanced |
|
6,Mechanical, electronic, equipment, generating sets of silencer insulation materials |
|
7,Industrial furnaces, thermal insulation material equipment |
|
Type | Thickness (mm) | Width (mm) | Length (m) | Gram Weight (g/m2) | Density (kg/m3) |
BY-3 | 3 | 1000/1200 | 30 | 230-260 | 110-120 |
BY-4 | 4 | 1000/1200 | 40 | 480-520 | 120-130 |
BY-5 | 5 | 1000/1200 | 30 | 600-700 | 120-140 |
BY-6 | 6 | 1000/1200 | 30 | 720-840 | 120-140 |
BY-8 | 8 | 1000/1200 | 20 | 760-1200 | 120-140 |
BY-10 | 10 | 1000/1200 | 20 | 1200-1500 | 120-150 |
BY-12 | 12 | 1000/1200 | 20 | 1200-1500 | 120-150 |
BY-15 | 15 | 1000/1200 | 15 | 2100-2400 | 140-160 |
BY-20 | 20 | 1000/1200 | 10 | 2800-3200 | 140-160 |
BY-25 | 25 | 1000/1200 | 10 | 3500-4300 | 140-160 |
Other sizes can be produced by customers’requirement. The Max width can be 2400mm. The error of specification and density are allowed to be ±10% The working temperatureE less than or eaual to 710°C
|
Contact Us
- Zibo Baoyang Fireproof Material Co., Ltd.
- Contact nameENID MI
- Phone86-0533-3980583
- AddressSouth of ShangZhuang Village,New-high Area of Zibo,ShanDong,China Zibo,Shandong
