Product Description
  1.    TDS Has the Lens from 1W to 300W Lens which is mainly for our LED.
  2.    we have 13mm - 22mm - 23mm PMMA lens for 1-5W LED in round / peanut / reflector / holder
  3.    We also have 10mm to 110mm Glass lens for 1W - 200W High Power LED
  4. We can design / OEM the lens you need with drawing.
  5. Made of borosilicate glass
  6. refractive index : 1.474
  7. Never get yellow comparing with PMMA material
  8. matching gasket and Stainless steel holder,reflector which make installation easily
  9.   Please contact us and tell us the lens data you need.
 Lens Chart

  The charge contains Convex Lens / Concave / Aspheric / spherical / stripe / pearl Lens. For more, please contact us.

NO. Model      Height(mm)) Stage Height(mm) Diameter(mm)
1 TDS-D21       7.04 2.62 20.9
2 TDS-D22-001 7.45 2.25 21.58
3 TDS-D22-002 7.5 2.2 21.45
4 TDS-D22-003 5.4 2.25 21.78
5 TDS-D28-001           10 2.5 27.85
6 TDS-D28-002      7.5 2.4 28
7 TDS-D30-001 9.9 2.7 29.5
8 TDS-D30-002 19.4 2.8 30
9 TDS-D32 8 2.5 32
10 TDS-D34 4.7 2.6 34
11 TDS-D38          2 2 38
12 TDS-D43-001 12 2.57 43
13 TDS-D43-002 15 2.57 43
14 TDS-D44       20 3.1 44
15 TDS-D45-001 15 3 44.5
16 TDS-D45-002  20 3 44.5
17 TDS-D45-003 19 2 45
18 TDS-D48 21.2 3 47.4
19 TDS-D49 23.1 3.3 48.7
20 TDS-D50-001 22 2 50
21 TDS-D50-002 18.5 2.6 50.8
22 TDS-D50-003 21.1 3.1 50.2
23 TDS-D50-004 22 3 50
24 TDS-D50-005   21 3 50.3
25 TDS-D50-006   22.5 2.5 50
26 TDS-D50-007 22 3 50
27 TDS-D50-008 18.5 2.5 50
28 TDS-D50-009 22.5 2.5
29 TDS-D51   21 3 51
30 TDS-D52 24 3
31 TDS-D54 21 3 54
32 TDS-D56 22.5 3.1 56.5
33 TDS-D63-001 10 3 63
34 TDS-D63-002 25.25 3.25 63.1
35 TDS-D63-003 24 3.3 63.2
36 TDS-D63-004 23.5 3.1 62.7
37 TDS-D63-005 24.8 3.2 62.8
38 TDS-D64-001 25.7 3.2 63.5
39 TDS-D64-002   25 3 64
40 TDS-D64-003 25.25 3.2 63.6
41 TDS-D65 24.2 3.4 65.1
42 TDS-D66-001     28.5 3.1 66.2
43 TDS-D66-002 24 3.4 66.15
44 TDS-D66-003 24 3.15 66.35
45 TDS-D67-001 23.5 3 67
46 TDS-D67-002 24.3 3.5 66.7
47 TDS-D67-003 23 3 66.5
48 TDS-D67-004 23 3 66.8
49 TDS-D70  41.6 4 70.2
50 TDS-D74-001     23.3 3.45 74
51 TDS-D74-002     22.5 3.4 74
52 TDS-D75-001   24 3.5 74
53 TDS-D75-002 24.25 3.65 74.7
54 TDS-D78-001   34 4 78.25
55 TDS-D78-002 33.4 3.5 78
56 TDS-D78-003   33 3 78
57 TDS-D100 22.2 4.4 100



Application

77mm aspheric / spherical round glass lens77mm aspheric / spherical round glass lens

Lens Drawing

 Take 44mm Led lens drawing for example:77mm aspheric / spherical round glass lens
