JIABAO JIEBAO Warehouse Storage Pallet Rack System JB-10
| Place of Origin | Foshan,Guangdong |
| Brand Name | Jiebao |
| Model Number | JB-10 |
| Material | Cold-Rolled Steel |
| Type | Stroage Rack |
| Style | Heavy Duty |
| Capacity | 700-4000KG |
| Color | Customized |
| Size | Long 2300,2500,2700,3000,3300,3600mm |
| Width900,1000,1100,1200mm | |
| High 2000,2500,3000,3500,4000,4500,5000,5500,6000mm | |
| Upright | 100*70 (thickness 2.2mm) |
| Beams thickness | 1.5mm |
| Feature | Corrosion protection,Anti-rust |
| MOQ | 10 pcs |
| Packing | bubble packing/ box packing |
| Payment Terms | 30% deposit in advance, balance before shipment |
| Delivery Date | 10-14 days |
| Products | Specification | Loading Capacity | Regular Colour | Description |
(kg/layer) | ||||
Column |
H:2000-6000mm; W:900-1200mm |
Blue | powder coating | |
beam |
L:2300mm |
1500kg - 4000kg |
Orangered | |
L:2500mm |
1000kg - 3600kg | |||
L:2700mm |
800kg - 3400kg |
|||
L:3000mm |
700kg - 3200kg | |||
L:3300mm |
2000kg - 2800kg | |||
L:3600mm |
1200kg - 2200kg |
Plz tell us the following information for price.
1.Length*width*height of each shelf
2.Quantity of shelf
3.Quantity of main shelf and side shelf respectively
4.How many layers you want
5.Loading capacity of each layer
Layout drawing of supermarket shelf equipment for reference.
| Rich Experience |
Professional Technical Team |
Good Trade Reputation |
1. 28 years experiences of professional display shelf manufacturing. |
1. More than 200 sets of Punching Machines 2. Over 400 workers, Research and Development department is with excellent team of 50 skillful worker |
1.50 agencies Around the word buying our products regular from us. 2.Most of them had built the business with us for more than 10 years. |
Packing: metallic panels in carton. brackets and uprights in bubble foam
Q: Are you manufacturer or trading company?
A: We are manufacturer. Our factory has been specializing in supermarket shelves, warehouse racks since 1988.
Q: Where is your factory? Can I visit ?
A: Our factory is located in Foshan, Guangdong. You are warmly welcome to visit whenever you are available.
Q: What is your delivery time?
A: In general, within 15 days. It also depends on the order quantity and shelving design.
Q: What is the term of payment?
A: Payment terms: 30% of deposit upon signing the PI, and balance will be cleared by T/T before delivery.
Q: Are samples available?
A: Yes, samples are available at any time. We charge some sample cost and will return it during the next order.
Q: Could you produce according to customers’ design?
A: Sure, we have two very rich experience engineers in charge of customizing shelves service.
Q: Do you produce shelf with different kinds of materials?
A: Yes,our products are mainly made of metal but we also produce accessory shelves or displays with wood,glass,etc.
Q: What are starter rack and add on rack?
A: The difference between these two kinds of racks is upright. Starter rack have 2 uprights and add on rack is the continue rack with only 1 upright. For example, if there are 15 wall racks against the wall, the structure will be 1 starter rack+ 14 add on racks.
Q: What is the manner of package?
A: Generally, gondola supermarket shelf shelves are flat packed by air bubble film/ film in standard export cartons. Other packing like wooden box are available to clients’ requirement.
