Home > Products > Dip Power 10mm LED > 10mm Round led diode for underwater light
10mm Round led diode for underwater light
USD $0.03 - $0.04
/ Piece
1000 Pieces(Min.Order)
- 1000000 Piece / Pieces per Month
- SHANGHAI
- Credit Card PayPal
You May Like
Product Details
| Model Number | TDS-1012L Series | Chip Material | InGaN | |
| Emitting Color | Other, Warm / pure / cool white | Luminous Intensity | 10000-20000mcd | |
| Luminous Flux(lm) | 10-15 | Optical Attenuation(%) | 0.0005 | |
| Power | Other, 0.06W, 0.06W | Power Dissipation | 0.06 | |
| Color Rendering Index(Ra) | 75 | Color Temperature | 2000-25000K | |
| Operating Temperature(℃) | -20, 80 | Storage Temperature(℃) | -30, 70 | |
| Place of Origin | Jiangsu, China | Brand Name | TDS | |
| Certification | CE |
Product Description
TDS Recommend you to How to Select / Order The 10mm LED ?
1. Long pin / short pin
2.Lens Color: water clear / diffused / foggy milky
3.Viewing angle: 10D 20-30D
3.Color: Red / Green / Blue / Yellow Green / White / Pink
| Part Number | Chip Material | Emitted Color | λD(nm) CCT Typ. | Lens Color | V(mcd)@IF=20mA | VF(V)@IF=20mA | Viewing Angle 2θ½ | |||
| Min. | Max. | Min. | Max. | |||||||
| TDS-1012LR3CN | AlGaInP | Red | 625-630 | Water Clear | 8000 | 9000 | 1.9 | 2.3 | 20-30 | |
| TDS-1012LY2CN | AlGaInP | Yellow | 585-595 | Water Clear | 8000 | 9000 | 1.9 | 2.3 | 20-30 | |
| TDS-1012KB4CN | InGaN | Blue | 460-470 | Water Clear | 8000 | 9000 | 3.0 | 3.4 | 20-30 | |
| TDS-1012QG4CN | InGaN | Green | 520-530 | Water Clear | 8000 | 9000 | 3.0 | 3.4 | 20-30 | |
| TDS-1012KW4CN | InGaN | W White | 2900-4000K | Water Clear | 8000 | 9000 | 3.0 | 3.4 | 20-30 | |
| TDS-1012KW2CN | InGaN | White | 5000-25000K | Water Clear | 8000 | 9000 | 3.0 | 3.4 | 20-30 | |
Test Photo
