China Electric Hydraulic Scissor Lift Table Working Platform Self Propelled Scissor Lift Indoor Stationary Use
US$ 16,000 - 50,000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
Santo
Model Number:
Self-propelled
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Customized Electric Industry Crane , Overhead Crane Gantry Crane Railway CraneUS$ 9,000 - 90,000MOQ: 1 Set -
30 Years Crane Experience 1 Ton to 550 Ton Industry Application Quality as World Leading Level and Agent Price Overhead CraneUS$ 9,000 - 90,000MOQ: 1 Set
-
Workshop Electric Hydraulic Grab Crane 20tUS$ 2,000 - 120,000MOQ: 1 Set
-
Widely Used Waste Grab Overhead Crane Traveling Crane Grab Bridge Crane 10tUS$ 2,000 - 120,000MOQ: 1 Set
-
Traveling Traveling Crane Grab Bridge Crane 20t With Low PriceUS$ 2,000 - 120,000MOQ: 1 Set
Place of Origin
China
Brand Name
Santo
Model Number
Self-propelled
Lift Mechanism
Lift Chain
Lift Drive / Actuation
Hydraulic
Power
3KW
Rated Loading Capacity
500kg-1000kg
Min. Lifting Height
120mm
Max. Lifting Height
10000mm
Table Size
1200*1000mm
Overall Dimensions
1500*1200*200mm
Weight
850kg
Certification
CE
Warranty
12 months
After-sales Service Provided
Overseas service center available
China Electric Hydraulic Scissor Lift Table Working Platform Self propelled Scissor lift indoor Stationary Use
| Movable Hydraulic Scissor Lift | |
|
Suitable for one single person operation, mainly used in electric power, communication, airports, convention and exhibition center, hotel, supermarket, factory, station, dock, station and other places. Features:
| |
| Type | SJY3 | SJY6 | SJY7.5 | SJY9 | SJY11 | SJY12 | |
| Max. working height | mm | 3000 | 6000 | 7500 | 9000 | 11000 | 12000 |
| Low table height | mm | 850 | 980 | 1250 | 1500 | 1600 | 1700 |
| Table size | mm | 1300×700 | 1850×880 | 1800×1000 | 1800×1000 | 2100×1150 | 2450×1350 |
| Capacity | kg | 450 | 450 | 450 | 450 | 450 | 450 |
| Up time | s | 16 | 54 | 72 | 83 | 88 | 90 |
| Power supply | V/Hz | 380/50 | 380/50 | 380/50 | 380/50 | 380/50 | 380/50 |
| Power | kw | 0.75 | 1.1 | 1.5 | 1.5 | 2.2 | 3.0 |
| Length | mm | 1450 | 2000 | 2000 | 2000 | 2250 | 2600 |
| Width | mm | 900 | 1080 | 1200 | 1200 | 1350 | 1550 |
| Height | mm | 980 | 980 | 1250 | 1500 | 1600 | 1700 |
| Deadweight | kg | 400 | 650 | 1100 | 1260 | 1380 | 1850 |
| Type | SJY14 | SJY16 | SJY613 | SJY916 | SJY1216 | ||
| Max. working height | mm | 14000 | 16000 | 6000 | 9000 | 12000 | |
| Low table height | mm | 1800 | 1980 | 1300 | 1600 | 1600 | |
| Table size | mm | 2450×1350 | 2700×1500 | 1800×1000 | 1800×1200 | 2500×1500 | |
| Capacity | kg | 450 | 300 | 1000 | 1000 | 1000 | |
| Up time | s | 120 | 130 | 80 | 108 | 120 | |
| Power supply | V/Hz | 380/50 | 380/50 | 380/50 | 380/50 | 380/50 | |
| Power | kw | 3.0 | 3.0 | 2.2 | 3.0 | 3.0 | |
| Length | mm | 2600 | 2850 | 1950 | 1950 | 2600 | |
| Width | mm | 1550 | 1750 | 1200 | 1450 | 1550 | |
| Height | mm | 1800 | 2000 | 1300 | 1600 | 1600 | |
| Deadweight | kg | 2500 | 2680 | 1300 | 1850 | 2100 |
| Product showing | |
| Self-propelled Electric Hydraulic Scissor Lift | |
|
|
Suitable for one single person operation, mainly used in electric power, communication, airports, convention and exhibition center, hotel, supermarket, factory, station, dock, station and other places. |
| Type | C0210 | C0211 | C0212 | C0213 | |
| Capacity | kg | 380 | 230 | 450 | 320 |
| Max. extended load | kg | 113 | 113 | 113 | 113 |
| Table size | mm | 2270×810 | 2270×810 | 2270×1120 | 2270×1120 |
| Extended length | mm | 900 | 900 | 900 | 900 |
| Max. working height | mm | 8000 | 10000 | 10000 | 12000 |
| Max. table height | mm | 6000 | 8000 | 8000 | 10000 |
| Length | mm | 2480 | 2480 | 2480 | 2480 |
| Width | mm | 810 | 810 | 1150 | 1150 |
| Height | mm | 2210 | 2340 | 2340 | 2470 |
| Wheel base | mm | 1870 | 1870 | 1870 | 1870 |
| Up and down time | s | 24/54 | 28/40 | 28/38 | 45/36 |
| Moving speed | Km/h | 3.5/0.8 | 3.5/0.8 | 3.5/0.8 | 3.5/0.8 |
| Up motor | V/kw | 24/3 | 24/3 | 24/3 | 24/3 |
| Battery | V/Ah | 24/210 | 24/210 | 24/210 | 24/210 |
| Charger | V/A | 24/25 | 24/25 | 24/25 | 24/25 |
| Min. radius of turning circle | mm | 0/2190 | 0/2190 | 0/2330 | 0/2330 |
| Max. gradeability | % | 25 | 25 | 25 | 25 |
| Deadweight | kg | 1950 | 2100 | 2300 | 2530 |
| Product details | |
| Application | |
| Shipment | |
