110cc ATV With Reverse Gear With EPA LD-ATV341A-1

Specifications

Product Name: 110cc ATV

Model No.: LD-ATV341A-1

Engine

1. Type:4-Stroke, Single cylinder,Air-cooled

2. Displacement:110CC

3. Bore x Stroke (mm):52.4x49.5

4. Compression Ratio:8.8:1

5. Drive system:Chain

6. Start system:Electric

7. Ignition:CDI

8. Max Speed (km/h):43

9. Max Power KW(r/min):4.6/7500

10. Max Torque N.m(r/min):6.4/5500

Chassis

11. Suspension / Front & Rear:spring shock absorber

12. Brake / Front & Rear:Double Drum/Single Disc

13. Tires / Front & Rear:19X7-8 / 18X9.5-8

14. Rated load(kg):100

Product Size

15. LxWxH (mm):1690X1030X1070

16. Seat Height (mm):830

17. Ground Clearance (mm):220

18. Wheelbase (mm):1090

19. Fuel Capacity (L):1.5

20. Wheel tread(F/R)(mm):860/745

Packaging

21. G.W./N.W. (kg):131/117

22. Carton size(mm):1210x775x655

23. Container load:

40’HQ:92pcs
