Characteristics:
1.Good unitary function
2.Each one taking force symmetrically,circulate steady,high loading ransferring force,not easily quiver and cross the belt
3.Especially be applicable to pilsant load and impact vibration situations
4.long service life
Banded v belt is one of our main product,we can supply all kinds of banded v belt,and the effective length is 500mm—4000mm.
HIGHER DRIVE EFFICIENCY
The multiple V-rib design of POLY-V BELT provide more contact area than conventional V-belts. This in combination with the excellent flexibility of the Poly-V belt reduces transmission losses, towers heat build-up resulting in higher overall efficiency of the drive.
The details of specification are as follows:
Type |
Sectional dimension |
Group quantity |
Effective length (mm) |
||
b×h |
P(mm) |
θ° |
|||
A |
13.6×10.0 |
15.6 |
40 |
2 to 22 |
800-5080 |
B |
17.0×13.0 |
19.0 |
40 |
2 to 20 |
800-10000 |
C |
22.4×16.0 |
25.5 |
40 |
2 to 12 |
1000-10000 |
D |
32.8×21.5 |
37.0 |
40 |
2 to 9 |
2540-20000 |
3V(9J) |
9.5×10 |
10.3 |
40 |
3 to 5 |
800-4500 |
5V (15J) |
15.5×16 |
17.5 |
40 |
2 to 20 |
800-10000 |
8V (25J) |
25.4×25 |
28.6 |
40 |
2 to 12 |
2540-20000 |
NOTE:Our company possesses 1000 moulds to produce all kinds of type and material banded v-belts.
The effective length is 500mm-4000mm.
Test Method
Store and Transport
In storage and transportation of V-belt, direct sunshine as well as the soaking of rain of rain and snow should be kept clean and the contact with acid, alkali, oil and organic solutions should be prevented. Cares should be taken to prevent mechanical damage And, the belt should be 1 Km away from heat radiation devices.
The storage temperature should be -18--+40.
In storage,the belt should no be under heavy pressure so as to prevent deformation. The best method is to hang the belt on a crescent frame or put it on the shelt flatly.
The performance will be kept unchanged in one year when the belt is in storage under the above condition.
Taizhou Greco Rubber Belt Co.,Ltd, with high quality and competitive price and reliable service, our products involves in different varieties , Cogged belt , Classical V Belt,wedge wrapped v belt ,v belt ,pk belt ,pj belt ,auto belt, motocycle belt and so on. with different materials, techniques and usages. and the price is very very very competitive
About certification
Packing & shipping
The products will be packed in standard export cartons. carton size :65*38*25 cm or as client's requirements.
If inner packing is needed,we can offer it too.
If you have any requirements on the models and size, Don't hesitate to leave your message. You will get our reply within 12-24 hours of working days. We are committed to your 100% satisfaction.
If you have any requirements on the models and size, Don't hesitate to leave your message. You will get our reply within 12-24 hours of working days. We are committed to your 100% satisfaction.
