Specifications
5W 7W 10W 12W COB Ceiling Light Led Downlight Fixture3W 5W 7W 10W 12W 15W
Epistar LED Chip
50000hrs lifespan
5W 7W 10W 12W COB Ceiling Light Led Downlight Fixture
Specifications
| Model | BS-074-12W | CRI | WW | Ra>73 | |
| LED Brand | Epistar | PW / CW | Ra>78 | ||
| LED Power | 12W | Lamp Efficiency | >85% | ||
| LED Color | Warm white, Pure white, Cool white | Lumens Output | WW | 1000lm | |
| Input Voltage | AC85~265V | PW | 1025lm | ||
| Frequency Range | 50Hz – 60Hz | CW | 1050lm | ||
| Power Factor | >98% | Beam Angle | 90°120° | ||
| Power Efficiency | >85% | Installation | Recessed | ||
| Luminous Efficiency | 85LM/W | Housing Color | Silver Grey | ||
| Dimension | Φ140*60mm(120-125mm cut-out) | Working Temperature | -40°C ~ +55°C | ||
| Color Temperature | WW | 2700-3500K | Storage Temperature | -25°C ~ +65°C(25°Cbest) | |
| PW | 4000-5500K | Life span | 35000~50000hrs | ||
| CW | 6000-7000K | Certification | CE, RoHS, CB, CRP | ||
BS-074 Series Specifications
| Product Code | Power | Voltage | Power Factor | Level of Protection | Hole Size | Shine Angle | Luminance (lum) |
Lamp Size |
| BS-074 | 3W | AC85-265V | >0.95 | IP44 | 65mm | 120° | 255LM | Φ90xH55mm |
| BS-074 | 5W | AC85-265V | >0.95 | IP44 | 65mm | 120° | 425LM | Φ90xH55mm |
| BS-074 | 7W | AC85-265V | >0.95 | IP44 | 86mm | 120° | 595LM | Φ110xH60mm |
| BS-074 | 10W | AC85-265V | >0.95 | IP44 | 86mm | 120° | 850LM | Φ110xH60mm |
| BS-074 | 12W | AC85-265V | >0.95 | IP44 | 110mm | 120° | 1020LM | Φ140xH60mm |
| BS-074 | 15W | AC85-265V | >0.95 | IP44 | 110mm | 120° | 1275LM | Φ140xH60mm |
Features
• Round Type, White Housing Body
• Clear PC Cover, Independent Driver
• Testing reports are available
• Low power consumption, High power efficiency
• Compact of aluminum material, superior thermal performance, high applicability
• LED downlight series using high-purity aluminum material
• Nice shape design of the products, strong texture
• More compact and efficient heat dissipation
• Umlimited compatible luminaire available
Advantages
• With Epistar COB inside, 3 years warranty for LED light engine
• Pure aluminium material, good heat dissipation
• Easy installation with no ballast & starter needed, Instant start
• Easy to replace the LED light engine by twisting, even they have been made my different manufactures(YUSING, PHILIPS, OSRAM, GE)
• Low voltage constant current driver, more secure
• Lamp life time up to 30,000 hours, low-carbon cost and 3 years' warranty time
• Can save more than 80% energy than traditional bulbs
Typical Applications
• Holtels
• Office
• Meeting room
• supermarket
• Colthing stores
• home furnishing lighting
Quality Control
100% of the lamps will be tested and keep lighting for 24 hours to test its quality reliability , and we will also test its temperature after 24 hours’ lighting.
Then after it is cool we again test 100% of the lamps to see if it still work well . Each lamp should pass all these QC procedures before shipping to customer.
Trade Terms
• Payment term: T/T 30% deposit after order confirmed, the balance after goods ready before shipping . or L/C , or Western Union for small amount .
• Lead time : normally in 5~10 days after deposit received
• Sample policy : Samples are always availble for each model . Samples can be ready in 3~7 days once payment received .
• Shipping port: Guangzhou , China
• Discounts : We offer discount for big quantity.
Delivery Detail
•We ship goods by UPS/DHL/FEDEX/TNT express which takes 3~ 5 days to arrive, or by air cargo which takes about one week to arrive , or by sea which takes about one month to arrive , depending on your actual requirements.
Our Services
• For all your inquires about us or our products, we will reply you in detail within 24 hours
• We own well-tranied and passional sales & after- sale services who can speak fluent Engligh language
• We offer OEM services. Can print your own logo on product , can customize the retail box packing and other things.
• We have very experienced R&D engineers and we have strong ability to do ODM projects.
