120mm Inner Diameter 9w LED Downlight
Product Specification
| Series | BS-071 |
| Size(mm) | D86*70MM/ Cutout 65mm |
| Power (W) | 3W |
| IP | IP33 |
| Voltage(V) | AC85-265V |
| Color | WW/NW/PW/CW |
| View Angle | 45 |
| Luminous(lm) | 80-90Lm/W |
| Certification | CE, EMC, ROHS, LVD |
| Working Lifetime(Hour) | 50000 |
Features
High efficacy, Minimal 70lm/W, up to 80lm/W
Energy-saving, over 70% compared to incandescent lamps
Constant current driver, no strobe, no harmless to eyes and ensure LED lamp to have a long life time
Constant light output and even lighting
No mercury, environment friendly.
No mosquito around the lights compared with tradtional lights
No UV or IR radiation, Harmless to human body
| Product Code | Power | Voltage | Hole Size | Shine Angle | Luminance (lum) | Lamp Size |
| BS-071 | 1W | AC85-265V | 55mm | 45° 60° | 85LM | Φ68xH55mm |
| BS-071 | 3W | AC85-265V | 65mm | 45° 60° | 255LM | Φ86xH70mm |
| BS-071 | 5W | AC85-265V | 86mm | 45° 60° | 425LM | Φ105xH90mm |
| BS-071 | 7W | AC85-265V | 95mm | 45° 60° | 595LM | Φ105xH90mm |
| BS-071 | 9W | AC85-265V | 120mm | 45° 60° | 765LM | Φ135xH115mm |
| BS-071 | 12W | AC85-265V | 120mm | 45° 60° | 1020LM | Φ135xH115mm |
| BS-071 | 15W | AC85-265V | 140mm | 45° 60° | 1275LM | Φ160xH140mm |
| BS-071 | 18W | AC85-265V | 140mm | 45° 60° | 1530LM | Φ160xH140mm |
| BS-071 | 21W | AC85-265V | 150mm | 45° 60° | 1785LM | Φ180xH160mm |
| BS-071 | 24W | AC85-265V | 150mm | 45° 60° | 2040LM | Φ180xH160mm |
| BS-071 | 30W | AC85-265V | 200mm | 45° 60° | 2550LM | Φ230xH160mm |
QUALITY CONTROL
100% of the lamps will be tested and keep lighting for 24 hours to test its quality reliability , and we will also test its temperature after 24 hours’ lighting.
Then after it is cool we again test 100% of the lamps to see if it still work well . Each lamp should pass all these QC procedures before shipping to customer.
Application of 15w led panel light:
Residential Buildings, Home,Office, Meeting Room ,School, Library,Factory, Warehouse,Hotel, Casino,Parking Garage,Hospital,Commercial Center,Supermarket,Shopping mall,anywhere you want.
TRADE TERMS
1. Payment term: T/T 30% deposit after order confirmed, the balance after goods ready before shipping . or L/C , or Western Union for small amount .
2. Lead time : normally in 5~10 days after deposit received
3. Sample policy : Samples are always availble for each model . Samples can be ready in 3~7 days once payment received .
4. Shipping port: Guangzhou , China
5. Discounts : We offer discount for big quantity.
DELIVERY DETAIL
We ship goods by UPS/DHL/FEDEX/TNT express which takes 3~ 5 days to arrive, or by air cargo which takes about one week to arrive , or by sea which takes about one month to arrive , depending on your actual requirements.
OUR SERVICES
1. For all your inquires about us or our products, we will reply you in detail within 24 hours
2. We own well-tranied and passional sales & after- sale services who can speak fluent Engligh language
3. We offer OEM services. Can print your own logo on product , can customize the retail box packing and other things.
4. We have very experienced R&D engineers and we have strong ability to do ODM projects.
We specialized in the field of lighting products for years, and widely export to South America, Europe, Middle East and Africa etc. We do hope cooperate with you. If you have any question, please don't hesitate to contact us. thank you.
