Hot Sale & Cheap Price Active Infrared Motion Sensor (YS111)

Name: Hot Sale & Cheap Price Active Infrared Motion Sensor (YS111)
Brand: Yoursensor
SKU: 102151745
Availability: InStock

US$ 1 - 70 MOQ: 10 Pieces

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

Yoursensor

Model Number:

YS111

Ningbo Yoursensor Electronic Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name Yoursensor

Model Number YS111

Usage Position Sensor

Theory Optical Sensor

Output Other

1. It can detect the moving person or objects.

2. The quantity of detecting parts can be selected to suit different width of door wings.

3. Safe, beautiful, economic, comfortable.

Hot sale & Cheap price Active Infrared motion sensor (YS111)
Approval	CE & ISO9001
Scan area setting	Mechanical adjustment of wheels 500-2800mm, Triangle principle
Ambient temperature	-20 ℃ to +60 ℃, Deviate from set scan area 60℃
Distinguish black/white	Max20% White:scan area is larger Black:scan area is smaller, The distinguish between black and white according to scan area set
Detection area diameter	About 75mm light spot, Apply in 2000mm scan area
Type of ray	Type of ray, 880nm pulse modulation infrared light
Operation voltage	AC/DC12-36V
Current consumption	<100mA
Signal output	Relay,switch point Highest alternating voltage 48VDC/AC Highest alternating current 0.5ADC/AC Highest alternating capacitance volt-ampere/24watts Electrical isolation Rated current (resistive load) DC1A/24V Inductive load capacitive load Provide EDM quenching Resistive load
Detection response time	≤100ms
Operation mode	Motion or standstill mode, self-adaption
Function Indicator	LED, Blue-standby, Red-detect
IP	IP 52
Housing material	AL/ABS
Sensor dimension (sensor for revolving door)	750 31 20mm 900 31 20mm, 1200 31 20mm(optional) Length/Width/Hight
Sensor dimension (Motion light curtain sensor)	620 31 20mm, Length/Width/Hight
Electromagnetic compatibility	Anti-interference abide by EN61000-6-1,EN61000-6-2 Emission interference abide by EN61000-6-3,EN61000-6-4 Anti-interference abide by EN61000-6-1,EN61000-6-2 Emission interference abide by EN61000-6-3,EN61000-6-4
Detecting parts	1 piece or 2 pieces
