Specifications
Automatic Oscillating Knife Gasket Cutting Equipmentsshape:all
Cut:papers,plastics,rubbers,complex materials
Quiet:<60dba
Ruizhou Automatic Oscillating Knife Gasket Cutting Equipments
Ruizhou Automatic Oscillating Knife Gasket Cutting Equipments are very useful to cut gaskets.
THE ADVANTAGES
1. Dieless
free you from moulds and dies, ideal for sample-making and small production.
2. Creative
Using CNC system, you can design any shapes you like, to better suit your customers' needs, enlarging your products lines. Designs can be unlimited, creativity will be maximized.
3. Accurate
using oscillating knife technology, can cut all shapes, can cut exactly you want.
4. Versatile
multifunctional tool head, containing an oscillating blade, a pinch roller and a marking pen, capable of full-cutting, kiss-cutting, dotted-line cutting, creasing, laser-positioning, marking and drawing.
5. Easy
Simple user interface (liquid crystal display and touching button) and laser positioning, optimised design, easy to install, to set up and to use.
6. Professional
We have developped 21 kinds of knives to satisfy your cutting needs for different materials:
7. Quiet
Equipped with a silencer, the working sound is no more than 60dba.
8. Stronger Suction
RZCRT-C series is an improved version of oscillating knife CNC gasket cutting solution. Using vacuum cell suction, it is much strenghened as the suction power is concentrated on the specific spot on the materials. As a result, the power needed is less but stronger.
Specifications:
Mode |
RZCRT-1410C |
RZCRT-1813C |
RZCRT-2516C |
Cutting area |
1400mm*1000mm |
1800*1300mm |
2500*1600mm |
Working Character |
The gasket cutting machines are running at the same time with the computer operation .Fast finish data transfer and it can be used continuously. |
||
Cutting Speed |
0.8-1.5m/s |
||
Cutting thickness |
0.5-15mm |
||
Cutting materials |
Corrugated paper, Plastic, Rubber board, Grey board Paper, Complex Material, Underlay ,White board paper |
||
Knife |
Rotate blade head, Vibration blade head, Die cutter |
||
Applicable pen type |
Common sign pen, Oil pen, ball-point pen, Silver pen |
||
Measure to Fix Paper |
Divisioanl Vacuum |
||
Mechanical resolution |
0.07mm |
||
Software resolution |
0.025mm 0.01mm 0.1mm optional |
||
Interface of transmission |
Standard parallel and serial interface |
||
Buffer Capability |
Once fast transfer |
||
Command |
HP-GL and GP-GL compatible mode |
||
Digital control Panel |
Liquid crystal display and touching button |
||
Transmission materials |
Straight line guide track / Synchronous belt / Imported synchronous belt |
||
Motor |
Servo motor |
||
Oscillating Knife Head |
Oscillating knife head motor 20000 rotate/min |
||
Machine working voltage |
AC 220∨±10%,50HZ |
||
Air pump working voltage |
AC 380∨±10%,50HZ |
||
