Specifications
used in shoe and carton pattern design and cutting ,save your time and cost, improve efficiency and qualityRuizhou Carton Sample Cutting Machine |
Ruizhou carton sample cutting machine is efficient cutting solution for carton making industry. Introducing vibrating knife cutting technology, it is able to create accurate carton sample on corrugated paper, cardboard, rubber board and complex materials.
l Easy to use
u Carton sample cutting machine is specially designed for carton sample cutting. It’s easy to install, simple to set-up and learn the user interface, functionality to allow you to cut pieces quickly and efficiently, thus increasing your output and reducing your throughput time.
l Save time and money whilst improving quality
u Eliminates the cost and time you spend cutting paper patterns and making brass bound pattern boards.
u Greatly reduces the time taken to cut samples and graded paper patterns by hand
u Consistent accuracy throughout, utilizing commonly used CAD software, any modifications to the pattern can be re-cut quickly and efficiently.
u Reduces your lead times for samples, short production runs and overall pattern development time for both sampling and production, helping you to provide 'quick response' to your customers’ demands.
l Flexible
u When used with Ruizhou RECAD software, Ruizhou cutting tables are designed to work in the background which allows cutting and/or plotting pattern pieces whist you continue to develop other 2D patterns.
WHAT ARE THE FEATURES? |
l Tool Head
u A multifunctional tool head incorporating an oscillating knife, a marking pen and a creasing wheel.
l Compatibility
u Connectible to common CAD software, widely used for production of carton and paper or PVC patterns.
Available Model |
RZCAM-1209AF |
RZCAM-1509AF |
RZCAM-1512AF |
RZCAM-1812AF |
Working Area |
1200*920mm |
1500*920mm |
1500*1200mm |
1800*1200mm |
Cutting Materials |
Paper, Cardboard, Plastic board, Rubber board, Fiber sheet (up to 2mm) |
|||
Working Performance |
Cutting Speed: 600 - 900mm/s (Max.) |
|||
Cutting Thickness: 0.5 - 2mm | ||||
Mechanical Resolution: 0.07mm | ||||
Blade and Pen Type |
Blade: wolfram steel; |
|||
Pens: water-based fibertip, oil-based ballpoint, disposable ink pen. | ||||
Mat. hold-down method |
Vacuum Suction |
|||
Software Resolution |
0.025mm 0.01mm 0.1mm optional |
|||
Interface |
Standard parallel port or serial port |
|||
Command System |
HP-GL and GP-GL compatible mode |
|||
Power Consumption |
Machine: 200W AC 220±10%,50HZ |
|||
Vacuum Pump: 1100W AC 220±10%,50HZ | ||||
Feeding Mode |
Auto-feeding |
|||
