Vibrating knife digital leather cutting plotter, high quality & good price/performance ratio, best solution for leather cutting.Vibrating Knife Digital Leather Cutting Plotter, Leather Cutting Solution
Ruizhou Digital Leather Cutting System is a professional leather cutting solution. It is specially designed for footwear industry oriented to sample cutting and small bulk production. With an affordable investment, you are supposed to increase your productivity dramatically.
WHAT ARE THE BENEFITS
1. Saves money and time whilst improving quality
· Eliminates the cost and time you spend making pattern boards, dies and knives, by cutting your samples and fit trials directly.
· The skills needed when you are hand cutting upper and lining sample parts from leather are no longer required
· Consistent accuracy even with difficult materials, improving the quality of your footwear.
2. Cut developed pattern pieces immediately.
· Reduces your lead times for your chosen samples giving you that 'quick response' your customer's demand.
3. Flexible
· You can import parts from Ruizhou RECAD system, other third party 2D CAD systems via DXF format, or digitize parts directly using digitizer or scanner.
· You can cut a wide range of leather and synthetic materials
· You can do complex pattern cutting or decorative punching automatically in the cutting process.
4. Easy to use
· Prospector cutting systems incorporate the RECUT software which is specifically designed for projection cutting systems, RECUT has an easy to learn user interface and functionality to allow you to nest pieces quickly and efficiently, thus increasing your output and reducing your throughput time.
WHAT ARE THE FEATURES
1. Hardware Configuration:
· A projection cutting system based on the proven Ruizhou cutting table, with its established multifunctional tool head, which includes an Oscillating knife, stitch-marking pen and double-punch tool.
· Vacuum system with adjustable zone control. Ensures the material is held securely by concentrating the vacuum where the parts have been nested.
2. Control Software
· Prospector cutting systems incorporate the RECUT software which is designed specifically for projection cutting systems.
TECHNOLOGICAL SPECIFICATIONS
Model |
RZCUT-1410 |
RZCUT-2510 |
Working Area |
1400*1000mm |
2500*1000mm |
Cutting Materials |
Natural leather , Leatheroid, Synthetic materials, Cardboard etc. |
|
Working Performance |
Cutting Speed: 1-800mm/s |
|
Cutting Thickness: 0.5-3mm (common situation), 6mm (Max.) | ||
Material Clearance: ≥1mm | ||
Acceleration: 0.05m/ s2 | ||
Interface |
Standard parallel port or serial port |
|
Command Set |
HP-GL extended. |
|
Power Consumption |
Main Machine: AC 220∨±10%,50HZ; |
|
Vacuum Pump: 5.5 KW, AC 380∨±10%,50HZ | ||
Compressor: 1.5KW, AC 220V±,50HZ | ||
Material Hold-down Method |
Vacuum Suction |
|
Tool Head |
Servo-controlled Z-axis head Tz-P20-No tangential-module, dual-punch module and pen module |
|
Blade & Punch Tool |
Blade: Oscillating blade (optional Punching Tool: 3mm Diameter |
|
Vacuum Plate |
With adjustable vacuum zone. |
|
