Oxide Bonded Silicon Carbide Plate(90% SiC)
Negotiable
MOQ: 100 Metric Tons (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
China
Shape:
Plate
Material:
Silicon Carbide (SiC)
Payment & Shipping
Payment Methods:
Port of Shipment:
ANY CHINA PORT
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SiC Silicon Carbide Thermocouple Protection TubesUS$ 2 - 20MOQ: 10 Metric Tons -
SiC Heating Elements Silicon Carbide Heating PipeUS$ 2 - 200MOQ: 10 Metric Tons
-
2016 HOT SALE Si3N4 Bonded Sic PlateUS$ 2,300 - 2,500MOQ: 100 Metric Tons
-
Silicon Carbide Thermalcouple Protection TubeNegotiableMOQ: 20 Metric Tons
-
High Quality SiO2 Bonded SiC Plate(90% SiC)NegotiableMOQ: 100 Metric Tons
Place of Origin
China
Shape
Plate
Material
Silicon Carbide (SiC)
SiO2 Content (%)
>8%
SiC Content (%)
90%
Brand Name
DKJL
Characteristics:
It has the properties of high structural strength, high thermal conductivity,excellent thermal shock
resistance and good volume stability
Application:
It can be used in the lining of heat-exchanger in coke oven and other kind of heating equipments.
Item |
Index |
SiC , % min |
90 |
SiO2 , % min |
8 |
Bulk Density , g/cm3 |
2.55-2.7 |
Apparent Porosity , % max |
<15 |
Cold Crushing strength, MPa min |
>120 |
rupture strength , MPa min |
>30 |
Refractoriness ( SK ) |
1790 |
Initial soften point under load (°C) |
1650 |
Thermal Conductivity, w/m.k min |
15.3 |
thermal expansion coefficient, max |
<5.2x10-6/°C |
...
