Help Centerw. Housing C Coding Blue Color 4 Pin Plug Straight PCB Mount High Speed Data HSD Connector
Related Products
-
w. Housing D Coding Bordeaux Violet Color 4 Pin Plug Straight PCB Mount High Speed Data HSD ConnectorUS$ 2 - 6MOQ: 1 Piece -
w. Housing z Coding Waterblue Color 4 Pin Plug Straight PCB Mount High Speed Data HSD ConnectorUS$ 2 - 6MOQ: 1 Piece
-
Straight A Coding Black Crimp Female Jack HSD Connector With Housing for Dacar 535 538 4 Pole CableUS$ 2 - 6MOQ: 1 Piece
-
Right Angle Z Coding Waterblue Crimp Female Jack HSD Connector With Housing for Dacar 535 538 4 Pole CableUS$ 2 - 6MOQ: 1 Piece
-
Right Angle K Coding Curry Crimp Female Jack HSD Connector With Housing for Dacar 535 538 4 Pole CableUS$ 2 - 6MOQ: 1 Piece
Coding A Black Color 4 pin Plug right angle PCB mount High Speed Data HSD Connector w. housing
The high speed data (HSD) connector is normally used for the high speed data (HSD) connector system which is focused on various motor vehicle application areas such as the inside compartment for connections to displays, head units, cluster displays and rear seat infotainment modules.
Specification :
| Product Name | Straight plug PCB w. housing |
| Series | HSD Connector |
| Gender | plug |
| Configuration | Straight |
| Backend Type | PC-Board solder pins (-400) |
| Business Area | Automotive |
| Coax Contact | coax contact with plastic housing |
| Housing Design | single |
| Coding/Color FAKRA, HSD | C blue |
Materials :
• Body : PA66
• Terminal :Brass ,Au Plated / Nickel
• Base die castings:zinc
Mechanical:
• Insertion force : ≤30N
• Withdrawal force : ≥ 5N
• Locking force: ≥ 100N
• Durability :> 25 times
Electrical:
• Frequency : 0-2Ghz
• Impedance : 100Ω
• Insulation resistance: 1000MΩ Min , After swapping 500MΩ Min
• Contact resistance: 15MΩ Max, After swapping 40MΩ Max
• Withstand Voltage :250V AC
• Working Voltage: 100V DC
• Working Current: ≤ 1.5A DC
Environment:
• High Temperature: 240℃
• Working temperature : -40 ℃ -85 ℃
Application:
• Camera
• Display
• Consumer Ports
• Reverse image
• The central display
• Rear entertainment system
• Digital dashboards
1.Regular packaging:Tape &Reel
2. Pack according to customer requirements,such as slide card,blister card and so on.
3. The quotation is F.O.B Shanghai.
1.OEM
2.ODM
3.Offer the sample of the normal products 3-5 pieces,but buyer is responsible for charges.
Changzhou AIOpower New Energy T&S Co.,ltd is a manufacturer of RF/AV Connector with
well-equipped testing facilities and strong technical force.
With a wide range, good quality, reasonable prices and stylish designs, our products are
extensively used in home appliance,car,surveillance and other industries.
Our products are widely recognized and trusted by users and can meet continuously changing
economic and social needs.
We welcome new and old customers from all walks of life to contact us for future business
relationships and mutual success!
