19-23% Inert Alumina Packing Ball/ceramic Balls

19-23% Inert Alumina Packing Ball/ceramic Balls thumbnail-1
19-23% Inert Alumina Packing Ball/ceramic Balls thumbnail-2
19-23% Inert Alumina Packing Ball/ceramic Balls thumbnail-3
19-23% Inert Alumina Packing Ball/ceramic Balls thumbnail-4
19-23% Inert Alumina Packing Ball/ceramic Balls thumbnail-5
19-23% Inert Alumina Packing Ball/ceramic Balls thumbnail-6
19-23% Inert Alumina Packing Ball/ceramic Balls photo-1
19-23% Inert Alumina Packing Ball/ceramic Balls photo-2
19-23% Inert Alumina Packing Ball/ceramic Balls photo-3
19-23% Inert Alumina Packing Ball/ceramic Balls photo-4
19-23% Inert Alumina Packing Ball/ceramic Balls photo-5
19-23% Inert Alumina Packing Ball/ceramic Balls photo-6
US$ 200 - 500 MOQ: 1 Metric Ton
Key Specifications
Get Latest Price
Place of Origin:
Jiangxi, China
Type:
Ceramic Balls
Application:
Industrial Ceramic
Contact Supplier Request Quote Chat Now
Dkjl Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Any China Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangxi, China
Type Ceramic Balls
Application Industrial Ceramic
Material Alumina Ceramic
Brand Name DKJL

19-23% inert alumina packing ball/ceramic balls



Size: 3mm 6mm 13mm 19mm



Introduction:

Inert Alumina ball was made from very high quality chemical-porcelain clay materials, which has quite excellent stability, high mechanical strength and resistance to thermal shock, This makes them all ideal choice for support of all types of catalyst.



application: As the material to support and cover catalyst in the reactor ,inert alumina ball can buffer gas or liquids flush on catalyst so as to protect catalyst.It also can improve distribution of gas or liquid in the reactor.Therefore,its widely applied in petrochemical,chemical,fertilizer,gas and environmental protection industries.





3. Chemical composition & Physical properties







chemical compositions

ceramic support ball

Al2O3

> 17%

SiO3

< 75.0%

Fe2O3

< 1.00%

TiO3

< 1.00%

CaO

< 0.50%

MgO

< 0.5%

Na2O

< 2.00%

K2O

< 2.5%

physical analysis

ceramic support ball

bulk density kg/m3

1210-1430kg/m3

operating temperature °C

> 985°C

water absorption %

< 0.5%

moh’s hardness  scale

                                 > 6.5







index size

ceramic support ball

crushing strength

Kg/particle

KN/particle

1/8”(3mm)

>28

>0.28

1/4“(6mm)

>55

>0.54

3/8“(9mm)

>110

>1.08

1/2“(13mm)

>170

>1.67

3/4“(19mm)

>430

>4.21

1“(25mm)

>635

>6.22

1.5“(38mm)

>910

>8.92

2“(50mm)

>1000

>9.8







19-23% inert alumina packing ball/ceramic balls



19-23% inert alumina packing ball/ceramic balls



....
