top quality insulating brick for refractory lining
B series insulation bricks are made from high purity raw material according to different brick type to meet different requirement.They are ideal thermal insulation material usually used in industrial furnaces and heating pipe.
Our insulation bricks are in accordance with JIS Industrial Standard of JAPAN, have excellent properties as light weight,low ferrous,low shrinkage, atmosphere erosion resistant and so on.
Features and advantage:
1.light weight
2.low density
3.high strength,good thermal shock resistance
4. Low heat storage, low thermal conductivity
5.saving energy
6.Precise size
7.good thermal insulation effect
8.good quality and low price
Application:
It is widely used as a primary hot face refractory lining or as back-up insulation behind other refractory in furnace(such as carbon furnace,cracking furnace,heating furnace for oil refining,roller kiln, tunnel kiln.),flues, flues,refining vessels, heaters,regenerators and similar high temperature industrial equipment.
insulating brick Technical Specifications
|
Items |
Testing Temperature(°C) When reheated with 2% contracting rate |
Volume Density g/cm3 |
Compression Strength Mpa |
Thermal Conductivity kcal/mh°C (350°C) |
|
B |
B-1 |
900 |
≤0.70 |
≥2.50 |
≤0.17 |
B-2 |
1000 |
≤0.70 |
≥2.50 |
≤0.18 |
|
B-3 |
1100 |
≤0.75 |
≥2.50 |
≤0.20 |
|
B-4 |
1200 |
≤0.80 |
≥2.50 |
≤0.22 |
|
B-5 |
1300 |
≤0.80 |
≥2.50 |
≤0.23 |
|
B-6 |
1400 |
≤0.90 |
≥3.00 |
≤0.27 |
|
B-7 |
1500 |
≤1.00 |
≥3.00 |
≤0.31 |
|
Common size
Straight type |
Arch type |
Wedge type |
|
L×W×H (mm) 230×114×65 230×114×75 230×114×32 220×110×60 220×110×50 220×110×40 220×110×30 |
L×W×H/h (mm) 230×114×65/55 230×114×65/45 230×114×65/59 220×110×65/50 220×110×75/65 220×110×60/40 |
L×W×H/h (mm) 230×114×65/55 230×114×65/45 220×110×75/65 220×110×60/40 |
Other sizes according to customer requirements | ||
Pictures of insulating brick
Packingof insulating brick : Standard export wooden pallet with cardboard
Shipping: By vessel or by train from any Chinese port, Samples can be delivered by International express.
Pictures of insulating brick
DKJL refractories exporting company is one of the most professional suppliers of refractories in China. Our main products are refractory and thermal insulation materials, heating elements, and industrial ceramics. They are available in various sizes and shapes. Our products enjoy a good reputation for their excellent quality and service in domestic and international markets.
1. Timely response,
Timely response to your inquiry, multiple choice recommendations based on your demand, quickly respond mails and provide solutions.
2. Free sample
Sample and trial order are accepted for the quality evaluation.
3. Strict quality control
Arrange production on time and control quality strictly.
4. Shorter delivery time.
Book the earliest vessel or plane to guarantee the delivery time.
5. Professional Services
Provide all the detailed news and pictures from order to delivery;
Offer relative export documents and original certificate if needed;
Warm and considerable after-sale service
1.How can I get your prompt quotation of the insulating brick inquiry?
We can give you reply with quotation quickly if you kindly send the inquiry with following factors of the insulation brick: bulk density,working temperature,cold crushing strength,dimension( length*width *thickness), application and quantity.
2.What's the MOQ of trial order ?
No limit,We can offer the best suggestions and solutions according to your condition.
3:What is the MOQ(minimum order quantity )?
1 pallet.
4.Which payment terms are you accept?
T/T,LC,Western Union,moneygram are available for us.
5.After an order is placed, when to deliver?
15-25days after confirming the order
6.Is your company accept customization?
we accept OEM service.
7.How to solve the quality problems?
If the products are not conform to customer samples or have quality problems, our company will be responsible to make compensation for it based on enough evidences.
8.What is the HS code?
The HS code is 69022000
