Help CenterXD860 Mini Backhoe Loader
Related Products
-
XD860 Cheap Backhoe LoaderNegotiableMOQ: 1 Unit -
Construction Machine XD850 Backhoe LoaderUS$ 1 - 38,000MOQ: 1 Unit
-
Popular XD850 Backhoe LoaderUS$ 1 - 38,000MOQ: 1 Unit
-
Articulated XD850 2 Ton Backhoe LoaderUS$ 1 - 38,000MOQ: 1 Unit
-
Top Brand XD850 2 Ton Backhoe LoaderUS$ 1 - 38,000MOQ: 1 Unit
Specifications
mini backhoe loader1. Load 1.8 ton, 1.0cbm
2. backacter bucket capacity 0.3cbm
2. four-wheel drive, whole hydraulic control
I.Features&Benifits
1. Central articulated frame, smaller turning radius, mobile and flexible, lateral stability, ease of loading operations in a narrow venue.
2. Loading device appearance with reference to the advanced level in the world , the British company JCB's 3CX structure, mining device form factor reference John Deere 310SE structure, good looks, the cab with a large area of glass, the driver get more comfortable operation.
3.Air over hydraulic caliper disc foot brake system and external beam drum hand brake, safe and reliable braking.
4. The use of hydraulic transmission structure, and improve the reliability of the transmission system.
5.Full hydraulic steering, power shift, work unit hydraulically operated. The machine is easy to operate and flexible, smooth and reliable action.
6. The use of low-voltage wide-based off-road tires, the rear axle swing, has good off-road performance and performance.
7. Capable of lateral slip device excavation, broader digging range and scope.
8. The suspension damping 360 · swivel seat with armrest and seat belts to improve the comfort and safety of the drivers
II.Specifications
Overall Operating Weight |
7640KG |
Final Reducer |
Single Stage Final Reducer |
Transport Dimension |
Rated Loader of Axle |
7.5t |
|
L*W*H (mm) |
5910×2268×3760 |
Transmission System |
|
Wheel base |
2250mm |
Torque Converter |
|
Min. Ground Clearance |
300mm |
Model |
YJ280 |
Bucket Capacity |
1.0m3 |
Type |
Single-stage Three Elements |
Breakout Force |
38KN |
Max. Efficiency |
84.4% |
Loading Lifting Capacity |
2500KG |
Inlet Pressure |
0.4Mpa—0.55 Mpa |
Bucket Dumping Height |
2742mm |
Outlet Pressure |
1.2Mpa—1.5 Mpa |
Bucket Dumping Distance |
1062mm |
Cooling Method |
Oil-cooling Pressure Circulation |
Digging Depth |
52mm |
Gearbox |
|
Backhoe Capacity |
0.3 m3 |
Type |
Fixed Shaft Power Transmission |
Max. Digging Depth |
4082mm |
Oil Pressure of Clutch |
1373Kpa—1569 Kpa |
Swing Angle of Excavator Grab |
190o |
Gears |
Two Gears Ahead, Two Gears Astern |
Max. Pulling Force |
39KN |
Max.Speed |
22Km/h |
Engine |
Tyre |
||
Model |
LR4M3-G93 |
Model |
16/70-20 |
Type |
In Line Direct injection Four-Stroke and Injection Combustion Chamber |
Pressure of Front wheel |
0.22 Mpa |
Cylinder-Inside Diameter*Stroke |
4-110×120 |
Pressure of Back Wheel |
0.22 Mpa |
Rated Power |
65KW |
Brake System |
|
Rated Speed |
2400r/min |
Service Brake |
Air Over Oil Caliper Brake |
Min. Fuel Consumption |
≤216g/km.h |
External Type |
|
Max.Torque |
≥261.7N.M/1800r/min |
Self-regulation |
|
Displacement |
4.4L |
Self-balance |
|
Steering System |
Emergency Brake |
Operation Power Implementing brake |
|
Model of Steering Device |
BZZ5-250 |
Manual Operation Power Terminating Brake |
|
Steering Angle |
±36 o |
Hydraulic System |
|
Min. turning radius |
5018mm |
Digging Power of Excavator Grab |
46.5KN |
Pressure of the system |
12Mpa |
Digging Power of Dipper |
31KN |
Axle |
Bucket Lifting Time |
5.4S |
|
Manufacturer |
Feicheng Axle Factory |
Bucket Lowering Time |
3.1S |
Main Transmission Type |
Double Reduction |
Bucket Discharge Time |
2.0S |
The parameters are subject to change without notice | |||
