Wire Mesh Container With Front Drop Gate

Wire Mesh Container With Front Drop Gate thumbnail-1
Wire Mesh Container With Front Drop Gate photo-1
US$ 50 - 60 MOQ: 100 Units
Key Specifications
Get Latest Price
Place of Origin:
Liaoning, China
Brand Name:
HML, HML
Model Number:
Wire mesh container with front drop gate
Contact Supplier Request Quote Chat Now
Dalian Huameilong Metal Products Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Liaoning, China
Brand Name HML, HML
Model Number Wire mesh container with front drop gate
Type Other, Wire Container, Folding Container
Scale Medium Duty
Capacity 500KG

Specifications

Wire mesh container with front drop gate
1) zinc finish
2) saving space and stackable
3) 500KG loading capacity





   Wire mesh container with front drop gate

  Wire mesh container with front drop gateWire mesh container with front drop gate





Product Code F-17
External Dimension 1200MM(L) x 1000MM(W) x 1000MM(H)
Mesh Size 65x 120mm
Wire Guage  Ø10 - Ø 5.0mm
Capacity 500kg
Stackability 4 High
Weight 51kg
Finish Zinc plated
Remark Build products to your specifications
Features Bright electro zinc plated after welding for rust-free life
4-way forklift access
Front drop gate for easy access
Robust wire formed construction
Folds flat for space-saving shipping and storage
Long lasting, economical alternative to disposable packaging





Othe dimension available:



Model No. Exterior dimension Interior dimension Wire Guage Dimension of Grid Loading Capacity Weight Loaded in 1x 40' Container
L W H L W H mm mm kg kg
F-1 1140 830 980 1080 800 850 12---5.0 55*113 800 53.00 332
F-5 1200 920 1018 1110 890 880 12---5.0 51*118 800 61.00 228
F-17 1200 1000 1000 1170 995 845 10----5.0 65*120 500 50.50 276
F-21 1152 850 992 1055 800 855 4.8---14 50*120 800 53.60 340
F-22 1200 1030 1190 1075 965 1020 4.8---12 62*125 800 64.50 163
F-27 1182 992 1160 1115 962 1030 5---12 56*118 800 63 164
F-28 1200 1010 1200 1134 978 1050 5---12 62*125 800 73.50 168
F-29 1244 825 965 1161 790 785 5---12 54*100 800 51.00 216



Pack and stackable pictures for   European wire mesh container

Wire mesh container with front drop gate



Other simiar product:



Foldable wire mesh container  -F1

Wire mesh container with front drop gate











 Foldable wire mesh container  -F5













Wire mesh container with front drop gate









 Foldable wire mesh container -F22



Wire mesh container with front drop gate



 Foldable wire mesh container -F16( wine or Champagne wire container)



Wire mesh container with front drop gate















Dalian Huameilong Metal Products Co.Ltd ,one of the largest manufacturers of transportation security facilities,material handling equipments and welded wire mesh products in North China.We have already past the ISO 9001:2000 and B&V international well-known certification.

With more than 18 years of professional manufacturer experiences,we have sucessfully record in suppling to our customers in West European,North American,Australia,Mid East and etc and have win highly reputation among customers.

Main products include the wire mesh container,wire mesh decking,roll container,steel converter, wire mesh fence and other wire mesh products.With nearly 1200 tons of mesh products produced monthly in our modern 30000 square meters office and factory premises,coupled with 400 skillful technicians and engineers working round the clock,we can efficiently handle your volume needs.

The company has roll-forming machines,sheet metal and tube bending,cutting,punching and electronically controlled multiple projection welding machines to manufacture and other finished products catered to customers’ designs.With our own powder coating systems which are capable of meeting almost every decorative and functional powder coating need.

As we are located in Dalian,one of the biggest sea ports in North China,enabling us to provide efficient shipping and logistics service for your emergency orders. If you are interested in any one ,please contact with us now.



Corporate Culture: Quality is enterprises’ life and motivation and should be guaranteed by whole workers
