What could you get from us?
1.FREE and NO OBOLIGATION quote
2.Higher quality, reasonable price:
a. We have our own factory, so we can supply you the factory price.
b. Full set quality control system to guarantee the best quality
c. Third party inspection available upon requirement
3. Experienced Service:
a. Professional solusion:
With over 20 years producing experience, we can offer you our best solusion, and help you
to save money.
b. Design
We can translate your original drawing, offer best suggestion on design, or give you our unique
design according to your requires.
c.OEM surpport & customized size
Warehouse stackable metal post pallet
Specifications of post pallet
| Similar design, defferent sizes | |||||
| Model No. | Exterior Dimension |
Loading Capacity |
Finish | Quantities |
Total container |
| LxWxH(mm) | kg | sets | |||
| M1-Base | 1395x1060x310 | 1500 | Hot dip zinc | 220 | 1x40'HQ |
| M1-Post | 1200x60x2.5 | Hot dip zinc | 880 | ||
| M2-Base | 1875x1060x310 | 1500 | Hot dip zinc | 143 | 1x40'HQ |
| M2-Post | 1200x60x2.5 | Hot dip zinc | 572 | ||
| M4-Base | 1545x1050x310 | 1500 | Powder coating | 247 | 1x40'HQ |
| M4-Post | 1510x60x2.5 | Powder coating | 988 | ||
| M5-Base | 1200x1000x310 | 1000 | zinc | 255 | 1x40'HQ |
| M5-Post | 2000x60x2.5 | zinc | 1020 | ||
| M6-Base | 950x950x310 | 1000 | zinc | 160 | 1x40'HQ |
| M6-Post | 2100x60x2.5 | Hot dip zinc | 320 | ||
| Material | Mild steel Q235 | ||||
|
Application area |
Warehouse, logistic, recycling, etc. | ||||
| Remark | Costomized or OEM support | ||||
|
Key Features |
1.Ideal solution for palletized cargo. 2.eliminates the need for wooden pallets for loose cargo. 3.assembled and disassembled within seconds. 4.When not in use can be stowed away in less than 10% of space 5.No maintenance required 6 It will enable you to transform areas which are usually free into storage spaces. |
||||
Similar products of post pallet
with removable posts
Application of post pallet
It will enable you to transform areas which are usually free into storage spaces
Gold supplier of Alibaba for 11 years!
Skilled and highly controlled working process
With over 20 years metal products manufacturing experience
Dalian Huameilong Metal Products Co.Ltd , established in 1993,one of the largest manufacturers of transportation security facilities, material handling equipments and welded wire mesh products in North China.We have already
past the ISO 9001:2000 and B&V international well-known certification.
Corporate Culture: Quality is enterprises’ life and motivation and should be guaranteed by whole
workers
1, What is the material being used for your products?
---Mild steel Q235, Q195
2, How is the goods being packed?
---Plastic banding + Stretch film wrapped, palletized for easy loading and unloading with standard forklift
truck or pallet jack.
3, What is the payment terms I can get?
---TT or L/C at sight, DP etc
4, What kind of finish do you provide for your goods?
---A.Electro galvanized/Zinc plated: the zinc serves as a sacrificial anode( indoor storage)
B.Hot dip galanized: it forms a coating of corrosion-resistant zinc(indoor/outdoor and cold storage)
C.Powder coating: a type of coating that is applied as a free-flowing, dry powder(indoor/outdoor storage)
5, What is the loading capacity?
---In general, we have light duty(100~300kg) model,medium duty(400~800kg) model and
heavy duty(1000~1700kg) model available for your choice.
6 Which product can be used in cold storage?
---Mobile rack,wire container and roll cage are all widely used in cold storage.
7 I like your design, but couldn‘t find the right model from the products list, is custom size available?
---Yes, we do custom products and projects.
8 I would like to have my own design products and qty is not that big, is it ok?
---Yes, we can go with your custom design, no matter small or big qty, however, pls understand the cost
will be different.
9 I don't have drawing or picture available for th custom products, could you design it for me?
--Yes, we can make the best suitable design for you but do need to know the details, such as
a) dimension b) loading capacity c)stackability d)operation environment
10 What is the minimum quantity I can order?
--1x20'GP - qty is variable depend on the size
11 What is your average production lead time?
--2-3 weeks against formal order and deposit.
12 Do I get any guarantee from your company?
-3~10 years warranty in case that A) Proper handling during operation, correctly forklift handling while
stacking/unstacking B) Overloading is prohibited C) Environment request indoor, dry and not humid
circumstance, do not contact with any corrosive chemical material (for zn plated and powder coated proucts,
no limitation for hot dip galvanized)
