Specifications
Small construction Rotary Kiln1.High precision temperature control
2.High level automatic running
3.Low power consumption
Construction Rotary Kiln
Construction Rotary Kiln Application:
Construction rotary kiln main can be used for building material equipment.Rotary kiln can be divided into cement kiln, metallurgy chemical kiln and lime kiln according to different materials.
1 The motorization level of the barrel is high, and the production capacity is high.
2 The resistance that the material passes through the barrel is less, and the power consumption is low.
3 Application capability to different characters of materials is high.
4 The operation is stable, the operation fee is low, and the uniformity of product drying is good.
Construction rotary Kiln features:
Rotary Kiln in simple structure, convenient and reliable control of the production process, less wearing parts, high rates of operation, its not only used to calcine high-grade cement in cement plant, but also widely used in metallurgical, chemical, construction and other industries. The rotary kiln produced by our plant has strong structure, stable operation, high-quality products from the kiln and so on advantages,
Technical parameter of Construction Rotary Kiln:
|
Specifications (mm) |
Kiln demensions |
Output(t/h) |
Rotation speed(r/min) |
Motor power(kw) |
Weight |
Note | ||
Diameter(mm) |
Length(mm) |
Obliq-uity(%) |
(t) |
---- | ||||
Ø1.4x33 |
1.4 |
33 |
3 |
0.9-1.3 |
0.39-3.96 |
18.5 |
47.5 |
---- |
Ø1.6x36 |
1.6 |
36 |
4 |
1.2-1.9 |
0.26-2.63 |
22 |
52 |
---- |
Ø1.8x45 |
1.8 |
45 |
4 |
1.9-2.4 |
0.16-1.62 |
30 |
78.2 |
---- |
Ø1.9x39 |
1.9 |
39 |
4 |
1.65-3 |
0.29-2.93 |
30 |
77.59 |
---- |
Ø2.0x40 |
2 |
40 |
3 |
2.5-4 |
0.23-2.26 |
37 |
119.1 |
---- |
Ø2.2x45 |
2.2 |
45 |
3.5 |
3.4-5.4 |
0.21-2.44 |
45 |
128.3 |
---- |
| Ø2.5x40 | 2.5 |
40 |
3.5 |
9.0-10.5 |
0.44-2.44 |
55 |
149.61 |
---- |
| Ø2.5x50 | 2.5 |
50 | 3 | 6.25-7.4 | 0.62-1.86 | 55 | 187.37 | ---- |
| Ø2.5x54 | 2.5 | 54 | 3.5 | 6.9-8.5 | 0.48-1.45 | 55 | 196.29 | ---- |
| Ø2.7x42 | 2.7 | 42 | 3.5 | 10.0-11.0 | 0.10-1.52 | 55 | 198.5 | ---- |
| Ø2.8x44 | 2.8 | 44 | 3.5 | 12.5-13.5 | 0.437-2.18 | 55 | 201.58 | suspension preheating kiln |
| Ø3.0x45 | 3 | 45 | 3.5 | 12.8-14.5 | 0.5-2.47 | 75 | 210.94 | ---- |
| Ø3.0x48 | 3 | 48 | 3.5 | 25.6-29.3 | 0.6-3.48 | 100 | 237 | outside disassemble kiln |
| Ø3.0x60 | 3 | 60 | 3.5 | 12.3-14.1 | 0.3-2 | 100 | 310 | ---- |
| Ø3.2x50 | 3.2 | 50 | 4 | 40.5-42 | 0.6-3 | 125 | 278 | outside disassemble kiln |
