Plain Tee Grid Ceiling Grid Suspension Ceiling Mirror T Grid

1  Metal suspension ceiling system   product is the indispensible building decoration material used in the ceiling suspension system. It is applied for the installation of various ceiling panels like miner fiber board, gypsum board, PVC gypsum board and so on.

Material: Hot Dip or Cold Zinc.

24mm Flat
Main Runner: 24 x 32 x 3000 x 0.3 mm

Cross Runner 24 x 26 x 1200 x 0.3 mm
Cross Runner 24 x 26 x 600 x 0.3 mm

15mm Flat
Main Runner 15 x 32 x 3000 x 0.3 mm
Cross Runner 15 x 32 x 1200 x 0.3 mm
Cross Runner 15 x 32 x 600 x 0.3 mm

15mm Grooved (Shillout)
Main Runner 15 x 32 x 3000 x 0.30 mm
Cross Runner 15 x 32 x 1200 x 0.30 mm
Cross Runner 15 x 32 x 600 x 0.30 mm

Wall Angle
22 x 22 x 0.35 mm L Angle.
14 x 19 x 0.35 mm W angle

2  Surface: With beautiful appearance, rustproof, non-corroding, fire-resistant, high intensity, high toughness, convenient application and easy installation

3 Main Material: Standard galvanized steel strip and prepainted steel strip

4) Thickness: 0.4mm,0.35mm, 0.3mm, 0.26mm,0.23mm

5) Color: ivory-white ( optional)

6) surface treatment: lacquer, polyester, anodized aluminium / mirror
7) The length, width, thickness and color can be provided in accordance with customers' requirements

Specifications

1. Our production is made by the good quality materials and professional work teams

2. It is with nice looking and easy to install to save time and coast.

3. We can make any size by your orders

Advantage

1. Galvanized steel profile raw material is high quality hot dipped zinc galvanized steel strip, absolute damp proofing, heat insulation and high durability, high rust resistance.

2. The specification can follow up customer requirements.

3. Advanced equipment can make sure exactly size, high quality products.

Application

Supermarket, marketplace

Underground, air port, bus station
Building lobby, metro station

Hotel, restaurant, railway station

School, office, meeting room, hospital

Business building

Tips:

 If you have any special requirement, please advise us the length, width, height and the thickness, also the quantity. Thanks

 We are 19 year manufacturer, Product apply in: Asia, Mid East, Europe, South America, Africa, Australia and so on.

Quality inspection procedure

1. We have five strict QC processes including incoming materials QC, IPQC (in process QC on patrol), LQC (line QC), FQC (final product QC) and OQC (output QC before shipping).

2. High quality 1100 aluminum alloy or galvanized steel.

If you find any product problems in the first order, we will give you the new parts for free to replace in the next order.

The Product Photos Show

 Package Show:
