High frequency Inflatable sleeping bag welding machine
- 100 Set / Sets per Month
- shenzhen
- T/T Credit Card PayPal
- Huitai hot selling OEM auto hot plate sheet board plastic pallet welding machine
- Auto Plastic Pallet sheet plate board Hot Plate Welding Machine for pallet
- automatic PP board edge sealing machine, coroplast sheet layer pads welding machine
- Huitai plastic capillary tube welding machine plastic welders pvc plastic hot plate welding machine bonding
- PP Membrane Hot Filter Plate Chamber Filter Press Plate and Frame Filter Plate welding machine
- Plastic PP Membrane Hot Chamber Filter Press vertical Frame Filter Plate welding machine plate-and-frame belt
Product Details
Place of Origin: | Guangdong, China | Brand Name: | Jiazhao | Model Number: | JZ-10K-TR |
Voltage: | 380V | Power: | 8KVA / 15KVA | Frequency: | 27.12MHz |
Welding Area: | Customization | Dimensions: | 1.1*1.7*1.55m | Weight: | 700Kg |
Usage: | High frequency Inflatable sleeping bag welding machine | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
High frequency Inflatable sleeping bag welding machine
Model | JZ-5K-SB(RB) | JZ-8K-SB(RB) | JZ-10K-SB(RB) | JZ-12K-SB(RB) |
High frequency power | 5KW | 8KW | 10KW | 12KW |
Oscillation tube | 7T85RB | 7T69RB | 3069RB | E3130RB |
Biggest pressure | 470KG | 700KG | Customization | |
Gap of electrodes | 230mm | 210mm | ||
Press stroke | 200mm | |||
Size of upper plate | 200*350mm | 400*600mm | Customization | |
Size of lower plate | 400*600mm | 600*800mm | ||
Supply voltage | 220V/380V(50/60HZ) | 380V/60MHz | ||
Frequency | 27.12MHz or 40.68MHz | |||
Power input | 8.5KVA | 15KVA | 20KVA | |
Rectifier | Silicon diode | |||
Temp range | 0~200°C | |||
Station | Two work station push table or round turn table | |||
Operation mode | Full pneumatic | |||
Welding time | 0~10s adjustable | |||
Physical size | 1.1*2.0*1.8m | 1.1*2.7*1.85 | Customization |
- Use a vacuum tube, the output power is stable and reliable. High frequency Inflatable sleeping bag welding machine
- High sensitive spark over-current protects circuit, can automatically cut off high frequency and suppress spark. High frequency Inflatable sleeping bag welding machine
- Equipped with frequency stabilizer and high frequency shielding device, make the high frequency interference a lowest level. High frequency Inflatable sleeping bag welding machine
- Manually adjust the mold, horizontal and quadrangular adjustment, easily to adjust mold. High frequency Inflatable sleeping bag welding machine
- Can automatically complete two welding process, improve work efficiency. High frequency Inflatable sleeping bag welding machine
- Equipped American automatic over-current spark protection system, protects tube life and mold. High frequency Inflatable sleeping bag welding machine
- Use standard international industry band. High frequency Inflatable sleeping bag welding machine
- The Silicon tube has strong resistance to voltage, Taiwan “AIRTAC” pneumatic components and microswitch. High frequency Inflatable sleeping bag welding machine
- Taiwan “CKC” timestamp, precise locking time settings. High frequency Inflatable sleeping bag welding machine
Pre-sale services:
1. provide professional technical support;
2. send the product catalog and instruction manual;
3. if you have any question please contact us online or send us email, we promise we will give you a reply as soon as possible;
4. personal call or visit is warmly welcome
sale of services:
1. we promise honesty and enthusiasm, it’s our pleasure to serve you as you purchasing consultant.
2. We guarantee punctuality, quality and quantities strictly implement the terms of contract
After-sale service:
1. Where to buy our products for one year warranty and life long maintenance
2. 24 hours telephone service online
3. A large stock of components and parts, easily-worn parts.
Contact Us
- Shenzhen Jiazhao Hightech Co., Ltd.
- Contact nameNeal Yang
- Phone86-755-84586648
- Address1-2/floor,building 19,Dapu industrial park,Longdong Dashiling road,Longgang district,Shenzhen City Shenzhen,Guangdong
