2015 Best quality cheap price daylight high lumen smd 36w-40w square flat 1200x300 led panel light aquarium
| Model NO | Size | lumens | LED Type | LED qty | Color temperature |
| WJ-PL3030-12W | 300*300*11mm | 800lm±10% | 3014 | 100 | 2700K-6500K |
| WJ-PL3030-18W | 300*300*11mm | 1200lm±10% | 2835 | 96 | 2700K-6500K |
| WJ-PL3060-18W | 300*600*11mm | 1200lm±10% | 2835 | 100 | 2700K-6500K |
| WJ-PL3060-27W | 300*600*11mm | 1850lm±10% | 2835 | 144 | 2700K-6500K |
| WJ-PL30120-36W | 300*1200*11mm | 2700lm±10% | 2835 | 192 | 2700K-6500K |
| WJ-PL30120-45W | 300*1200*11mm | 3350lm±10% | 2835 | 216 | 2700K-6500K |
| WJ-PL30120-54W | 300*1200*11mm | 3900lm±10% | 2835 | 252 | 2700K-6500K |
| WJ-PL30120-60W | 300*1200*11mm | 4500lm±10% | 2835 | 280 | 2700K-6500K |
1.Imported Light Guide plate whose light transmission rate at 80% to assure
High brightness possibly.
2. Aluminum huousing with excellent thermal efficiencies.
3. 36W LED Panel light can achieve directional light output equal to traditional
72W grid lamp.
4. Good circuit design make sure that other LED still work usually even if one
of LED is damaged.
5. Super slim design,11mm thickness,fashion and good looking.
6. 3 Years limited warranty.
7. No UV or IR Light radiation.
8. Safety Standard: CE&ROHS and FCC.
9. Woks with worldwide electrical systems .
Model NO |
WJ-PL30120-36W |
|
Power |
36W |
|
Input volt |
AC85-265V |
|
Frequency |
50Hz-60Hz |
|
PF |
≥0.95 |
|
Working volt |
AC85V-AC265V |
|
LED QTY |
192PCS /2835SMD |
|
LED Brand |
Epistar |
|
LED Power |
36W |
|
LED Light efficency |
75~80lm/W |
|
Lumens |
Wam white |
2450-2550lm |
Natural white |
2700-2800lm |
|
Cool white |
2700-2800lm |
|
Luminous efficency |
>93% |
|
Color temperature |
Wam white |
2800K-3200K |
Natural white |
4000K-4500K |
|
Cool white |
6000K-6500K |
|
CRI(Ra) |
Wam white |
>68 |
Natural white |
>80 |
|
Cool white |
>75 |
|
Beam angle |
120° |
|
Environment temperature |
-10℃to+40℃ |
|
Storage temperature |
-25℃~65℃ (25℃ best) |
|
Lifespan |
50000 h |
|
Frame material |
Aluminum alloy |
|
Size |
295*1195*11mm |
|
Net weight |
4.7kg |
|
Installation |
Embedded/wall mounted/suspended |
|
Waterproof |
IP42 |
|
Certificates |
CE, RoHS FCC |
|
| Model NO | SIZE | QTY/CN | carton size | GW/CN | Qty for 20 Container |
| WJ-PL3030-12W | 300*300*11mm | 10 | 435*368*410mm | 11KG | 3650 |
| WJ-PL3030-18W | 300*300*11mm | 10 | 435*368*410mm | 11KG | 3650 |
| WJ-PL3060-18W | 300*600*11mm | 5 | 697*360*225mm | 14KG | 2125 |
| WJ-PL3060-27W | 300*600*11mm | 5 | 697*360*225mm | 14KG | 2125 |
| WJ-PL30120-36W | 300*1200*11mm | 4 | 1290*390*190mm | 24.5KG | 1120 |
| WJ-PL30120-45W | 300*1200*11mm | 4 | 1290*390*190mm | 24.5KG | 1120 |
| WJ-PL30120-54W | 300*1200*11mm | 4 | 1290*390*190mm | 24.5KG | 1120 |
| WJ-PL30120-60W | 300*1200*11mm | 4 | 1290*390*190mm | 24.5KG | 1120 |
| Remark:20" container's inner volume is 24CBM | |||||
