Modern Useful Automatic Longitudinal Rolling Seam Welding Machine for Train Fabrication
US$ 1,000,000 - 2,500,000
MOQ: 1 Combo
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Japan
Brand Name:
AN DE
Payment & Shipping
Payment Methods:
Port of Shipment:
F.O.B KEELUNG Port Taiwan
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Popular Advanced Automatic Longitudinal Rolling Seam Welding Machine for Train FabricationUS$ 1,000,000 - 2,500,000MOQ: 1 Combo -
New Design Automatic Longitudinal Rolling Seam Welding Machine for Train FabricationUS$ 1,000,000 - 2,500,000MOQ: 1 Combo
-
High Efficiency Seam Welding Machine for Corrugated SheetsUS$ 1,000,000 - 2,500,000MOQ: 1 Combo
-
Seam Welding Machine for Stainless Steel Corrugated SheetsUS$ 1,000,000 - 2,500,000MOQ: 1 Combo
-
Made in Japan High Efficiency Corrugated Sheets Seam Welding MachineUS$ 1,000,000 - 2,500,000MOQ: 1 Combo
Condition
New
Place of Origin
Japan
Brand Name
AN DE
Model Number
S00014
Forming Time
NO
Welding Mode
seam welder
Welding Diameter
Throat depth of electrode arm: 1200 mm
Dimensions
3954(W)mmx2309(H)mmx1650(D)
Weight
NO
Usage
Welding
Voltage
380/400/440 V
Power(W)
3.5kW
Certification
ISO9001
Warranty
one year
After-sales Service Provided
Engineers available to service machinery overseas
Modern useful automatic longitudinal rolling seam welding machine
for train fabrication
Product Description
SEAM WELDING SYSTEM MACHINE
Model |
Maximum input |
Maximum short-cricuit current |
Maximum Welding Pressure |
UICS-360-13 |
360KVA |
22000A |
15 KN |
- Use and Description of the Equipment
- The equipment is for seam welding the lap seams between the corrugated top plates and corrugated chassis floors.
- The equipment is in two sections: the welder and the worktable. Jobs are fixed and the welder will move.
- It can be easy to operate, safe and reliable to use, easy to maintain and repair.
- The seam welder shall be furnished with enough strength and rigidity. It shall be able to guaranteestable technical performances when working for 16hcontinuously.
- Material for seam welding (spot welding): SUS301L and SUS 304 stainless steel.
- Plate thickness: max. 2.0+2.0 mm, min. 0.6+0.6, effective longitudinal work range 26 m.
- Production program: 8h/shift, 1 car/shift (total length of weld seam about 200 m).
- The noise of the equipment shall not be more than 70 dB.
- Welding standard: The acceptance standard for quality of welded points for spot welding will follow Japanese standard JISZ3140-1989 (Way for Checking the Spot-welded Places) and JISE4049-1990 (Way for Design of Welded Joints of SS Plates for Rolling Stocks).
- The dimensions, e.g. relative heights, etc. of each part of the equipment shall meet ergonomics.
- Process flow:
Two corrugated plates are placed on the worktable; the fixture clamps at two ends the
lapped corrugated plates; tack welding is first done, then continuous seam welding is done,
or continuous seam welding is done directly.
