DSLAM5024 24 Ports ADSL DSLAM IP DSLAM

DSLAM5024 is a 24 ports IP based ADSL2+ DSLAM with splitter built-in. It terminates all the ATM circuits and converts traffic directly to deliver the most popular broadband IP services.

DSLAM5024 offers lower port count DSLAM available in the market place. It provides the least initial investment solution for Service Providers who want to start providing high speed internet access service in a low subscriber density location on existing copper twistered pair telephone lines.

DSLAM5024 is compliant with ITU G.992.5, G.992.3, G.992.1, the G.992.5 ADSL2+ technology is an enhanced version of the ADSL technology which provides cross-talk free deployment. The unit features maximum downstream rate up to 24Mbps and maximum reach distance over 6.5Km.

With the highly compact (1U height) and temperature hardened design, simple installation and easy adaptation to local POTS/ISDN splitter requirements, DSLAM5024 is an ideal solution for Triple-play requirements deployed in indoor and outdoor enclosures.

Features

  Supports ANSI T1.413 Issue 2, ITU G.992.5, G.992.3,G.992.1 (G.dmt), ITU-T G.992.2 (G.lite)
  One 10/100 BASE-TX ports for uplink with auto-negotiating
  24 ADSL2+ Ports
  Support Annex M(optional)

  Support 802.1P, STP
  Support 802.1Q
  Multimode (automatic modulation detection)

  Supports packets transmit and receive statistics report
  Support NAT(optional)
  Support DHCP server(optional)
  Support DHCP relay
  Support multiple PVC QoS
  Provides optimal rate/reach performance
  Higher rates by limiting reach (up to 24.0 Mbps)
  Longer reach by reducing rate (distance up to 6.5 Km)
  Bandwidth Management control on each port at 32kbps interval.

Network Configuration Modes

  Gateway
  Router
  Bridge

Management

  Web based management
  SNMP-based GUI EMS
  Local RS-232 CLI
  Remote in-band SNMP/TELNET management
  Firmware upgradeable via web, FTP or TFTP

Hardware Configuration

  2 RJ45 for Uplink
  1 TELCO-50 connectors ( including 24pairs phone line) link to PSTN
  1 TELCO-50 connectors ( including 24pairs phone line) link to ADSL2+ users
  1 DB9 male (Null Modem) for Local Management

  Dimensions: 440mm(W) x 325mm(D)in x 44.5mm(H)
  Weight: 6.0Kg

Input Power

  AC Power Model: 90VAC ~ 260 VAC, 50-60 Hz

  DC Power Model: -40VDC ~ -60 VDC
  Power Consumption: 40 watts

Operation Parameters

  Operating Temperature: 0 to 50°C
  Storage Temperature: -40~+80°C
  Operating Humidity: 5% to 95% non-condensing
  Operating Altitude: -200ft.to +15,000ft
  Reliability: MTBF 140,000 hrs minimum
