Specifications
1.Temperature: -45~ +20'C .general purpose cold rooms & Freezer rooms for supermarket
3.Easy to use and maintenance.
general purpose cold rooms & Freezer rooms for supermarket
Feature of Cold room for general purpose cold rooms & Freezer rooms for supermarket
1.Temperature: -45~ +20'C
2.Size: Customization.
3.ISO9001,CE,Turnkey projects.
4.Components: Condensing unit, evaporator, PU panel, cold room door
5.Functions: freshkeeping storage for food refrigeration, industry refrigeration, fresh preservation of fruits and vegetables, large supermarket, cold storage of hotels ect.
6.Compressor brand: Bitzer,Emerson copeland,Danfoss,Tecumseh4.ISO9001,CE,Turnkey projects.
7.Easy installation,economical and energy saving,environmental friendly,reliable quality,professional service
8.Excellent quality ,Dependable performance,Easy installation,Economical and Energy saving,Environmental friendly,Reliable quality,Professional service.
| Size: Customization. | |||
| Classification | Small | Middle | Large |
| Volume Range | <500m3 | 500~10000m3 | >10000m3 |
Components for general purpose cold rooms & Freezer rooms for supermarket :
1.Condensing unit for general purpose cold rooms & Freezer rooms for supermarket :
Bitzer,Emerson copeland,Danfoss,Tecumseh
Air Cooled Type |
Conderser Fan |
Water Cooled Type |
water cooled condenser and cooling tower |
Evaporative Cooled Type |
Evaporative Condenser |
2.High efficiency air-cooler for general purpose cold rooms & Freezer rooms for supermarket :
Customized air-cooler.
Water defrosting or electrical deforesting evaporator defrost faster, save operating costs.
3.Insulation Panel for general purpose cold rooms & Freezer rooms for supermarket :
Use 100%polyurethane insulation panel,density about 38~46kg/m3,with gasket,with flame retardant,panel thickness:100mm~200mm, standard width of panel is 960mm
Polyurethane insulation board design for cold room, the main steel structure to facilitate construction. Portable sliding doors, and out of cold storage more convenient, easy to operate.
Thickness of cold room panel |
Application temperature |
50mm |
Temperature 5°C or above |
75mm |
Temperature -5°C or above |
100mm |
Temperature -25°C or above |
150mm |
Temperature -45°C or above |
200mm |
Temperature -55°C or above |
4.Doors for general purpose cold rooms & Freezer rooms for supermarket :
1.Swing door and sliding door for choice.
2.Swing door:manual opened,automatic,etc.
3.Door board made with special pressing technology PU material.
4.Door frame:color steel or stainless steel.
5.Surface material:color steel or stainless steel with protecting film.
5.Other accessories for general purpose cold rooms & Freezer rooms for supermarket : world-famous brands, like Danfoss, Castle, Every Control, Siemens, LG
Applications:
Food (meat, vegetable, fruit, dairy, drink), Medicine, Chemical, Electronics,etc.
Storage products |
Storage temperature approach |
Vegetables, Fruit chlling storage |
-5~5 'C |
Drink, Beer chilling storage |
2~8'C |
Meat, Fish freezing storage |
-18~-25'C |
Meat, Fish blast freezer |
-35~-40'C |
Medicine chilling storage |
2-8'C |
Medicne freezing storage |
-20'C |
Our advantages:
1.ORGREN Cold room have abundant experience in trading and installation abroad for many years..
2.ORGREN can provide the most reasonable configuration and price of cold room for customers.
Customer case:
It is portable cold room with high insulating PU Panel, reliable quality compressor and unit cooler, and other accessories. the size depends on your stock tons and temperature.
We can do customized dimension according to customers'requirements. We have access to all the leading Cold Room refrigerators brands and can offer independent advice, and recommend the right equipment to meet your business requirements.
To make a fast and detailed quotation for you,we would like you to answer some questions about this product as following:
1.What’s the products do you want to store in this cold room?
2.Will this cold room be installed inside building or put outside?
3.Could you provide the detailed inside dimension of this cold room?(m)
4.What’s the material of cold room panel,Polyurethane or EPS ?(Including the wall panel,floor and roof panel)
5.What’s the thickness of cold room panel?(Including the wall panel, floor and roof panel)(mm)
6.Which kind of door do you prefer,Sliding type or hing type? Color steel or stainless steel?
7.How much kilograms of products will be put in cold room per once(kg/once)?
8.What’s the required temperature inside the cold room(°C)?
9.What’s the ambient temperature?
10.Original temperature of products before put into the cold room(°C)
11.How many hours do you want to cool the products down to the required temperature?
12.Which refrigerant required for the refrigeration unit? R22 or R404A,R134A or others?
13.What’s the voltage/phase/frequency in your place?
Service Schedule:
