Cold Rooms For Flori-Culture Segment
Feature of Cold room
1.Temperature: -45~ +20'C
2.Size: Customization
3.ISO9001,CE,Turnkey projects
4.Components: Condensing unit, evaporator,Modular insulation PU panel, CAM hook,cold room door
5.Functions: freshkeeping storage for food refrigeration, industry refrigeration, fresh preservation of fruits and vegetables, large supermarket, cold storage of hotels ect.
6.Compressor brand: Bitzer,Emerson copeland,Danfoss,Tecumseh4.ISO9001,CE,Turnkey projects
7.Easy installation,economical and energy saving,environmental friendly,reliable quality,high efficiency,professional service
8.Refrigerant:R22,R404A,Glycol secondary refrigerant
9.Defrost type: Electric defrosting,water defrosting
10.Excellent quality ,Dependable performance,Easy installation,Economical and Energy saving,Environmental friendly,Reliable quality,Professional service
Components:
1.Condensing unit:
Bitzer,Emerson copeland,Danfoss,Tecumseh
Air Cooled Type |
Conderser Fan |
Water Cooled Type |
water cooled condenser and cooling tower |
Evaporative Cooled Type |
Evaporative Condenser |
2.High efficiency air-cooler:
Customized air-cooler.
Water defrosting or electrical deforesting evaporator defrost faster, save operating costs.
3.Insulation PU Panel:
use100%polyurethane insulation panel,density about 38~46kg/m3,with gasket,with flame retardant,panel thickness:100mm~200mm, standard width of panel is 960mm.
Polyurethane insulation board design for cold room, the main steel structure to facilitate construction. Portable sliding doors, and out of cold storage more convenient, easy to operate.
Thickness of cold room panel |
Application temperature |
50mm |
Temperature 5°C or above |
75mm |
Temperature -5°C or above |
100mm |
Temperature -25°C or above |
150mm |
Temperature -45°C or above |
200mm |
Temperature -55°C or above |
4.Doors:
1.Swing door and sliding door for choice.
2.Swing door: manual opened,automatic,etc.
3.Door board made with special pressing technology PU material.
4.Door frame: color steel or stainless steel.
5.Surface material: color steel or stainless steel with protecting film.
5.Other accessories: world-famous brands, like Danfoss, Castle, Every Control, Siemens, LG
Applications:
Food (meat, vegetable, fruit, dairy, drink), Medicine, Chemical, Electronics,etc.
Storage products |
Storage temperature approach |
Vegetables, Fruit chilling storage |
-5~5 'C |
Drink, Beer chilling storage |
2~8'C |
Meat, Fish freezing storage |
-18~-25'C |
Meat, Fish blast freezer |
-35~-40'C |
Medicine chilling storage |
2-8'C |
Medicine freezing storage |
-20'C |
Detailed Product Description
Insulation Material: polyurethane sandwich insulation panel
Insulation Material Thickness: 50mm,75mm,100mm,120mm,150mm,180mm,200mm,250mm
Insulation Material Density: ≥42Kg per cubic metre
Steel Plate Thickness:0.5mm,0.4mm,0.32mm
Insulation Material Fire Rating: B2
Connection: Concave and convex chamfer CAM lock hook connection
Corners Connection: L type angle panel
Equipment Configuration: Condensing unit,air cooler,Condenser, Reservoirs, Gas-Liquid Separator, Oil Separator, H/L Pressure Controller, Condensing Pressure Controller, liquid Sight Glass, Solenoid Valve, Filter, H/L Pressure Gauge, Oil Pressure Gauge, Junction Box
Brand Compendents: Danfoss, Alco, Castol, Bitzer,Emerson copeland,Danfoss,Tecumseh
Electric Control Box: With CE Mark
Electrical Element Brand: Schneider, LG, Siemens
Others:
Warranty: 1 year
Product Type: cold room,cooling room,freezer room,cold storage room
Dimension(L*W*H): Customized for cold storage room
Place of Origin: Shandong, China (Mainland)
We have access to all the leading Cold Room refrigerators brands and can offer independent advice, and recommend the right equipment to meet your business requirements.
To make a fast and detailed quotation for you,we would like you to answer some questions
about this product as following:
1.What’s the products do you want to store in this cold room?
2.Will this cold room be installed inside building or put outside?
3.Could you provide the detailed inside dimension of this cold room?(m)
4.What’s the material of cold room panel,Polyurethane or EPS ?(Including the wall panel,floor and roof panel)
5.What’s the thickness of cold room panel?(Including the wall panel, floor and roof panel)(mm)
6.Which kind of door do you prefer,Sliding type or hing type? Color steel or stainless steel?
7.How much kilograms of products will be put in cold room per once(kg/once)?
8.What’s the required temperature inside the cold room(°C)?
9.What’s the ambient temperature?
10.Original temperature of products before put into the cold room(°C)
11.How many hours do you want to cool the products down to the required temperature?
12.Which refrigerant required for the refrigeration unit? R22 or R404A,R134A or others?
13.What’s the voltage/phase/frequency in your place?
