Home > Lights & Lighting > LED Interior Lighting > LED Tube > Ballast Bypass 4ft 4000k Led t8 Lamp 15 Watt t8 Led Tube 1800 Lumens

Ballast Bypass 4ft 4000k Led t8 Lamp 15 Watt t8 Led Tube 1800 Lumens

Name: Ballast Bypass 4ft 4000k Led t8 Lamp 15 Watt t8 Led Tube 1800 Lumens
Brand: Alite LED
SKU: 101970285
Availability: InStock

Alite Co., Ltd.

Ballast Bypass 4ft 4000k Led t8 Lamp 15 Watt t8 Led Tube 1800 Lumens thumbnail-1

Ballast Bypass 4ft 4000k Led t8 Lamp 15 Watt t8 Led Tube 1800 Lumens thumbnail-2

Ballast Bypass 4ft 4000k Led t8 Lamp 15 Watt t8 Led Tube 1800 Lumens thumbnail-3

Ballast Bypass 4ft 4000k Led t8 Lamp 15 Watt t8 Led Tube 1800 Lumens thumbnail-4

Ballast Bypass 4ft 4000k Led t8 Lamp 15 Watt t8 Led Tube 1800 Lumens thumbnail-5

Ballast Bypass 4ft 4000k Led t8 Lamp 15 Watt t8 Led Tube 1800 Lumens thumbnail-6

Ballast Bypass 4ft 4000k Led t8 Lamp 15 Watt t8 Led Tube 1800 Lumens photo-1

Ballast Bypass 4ft 4000k Led t8 Lamp 15 Watt t8 Led Tube 1800 Lumens photo-2

Ballast Bypass 4ft 4000k Led t8 Lamp 15 Watt t8 Led Tube 1800 Lumens photo-3

Ballast Bypass 4ft 4000k Led t8 Lamp 15 Watt t8 Led Tube 1800 Lumens photo-4

Ballast Bypass 4ft 4000k Led t8 Lamp 15 Watt t8 Led Tube 1800 Lumens photo-5

Ballast Bypass 4ft 4000k Led t8 Lamp 15 Watt t8 Led Tube 1800 Lumens photo-6

US$ 5 - 7 MOQ: 25 Pieces

Key Specifications

Get Latest Price

LED Light Source:

SMD2835

Warranty(Years):

Input Voltage(V):

AC100-277V

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

Yantian

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

LED Light Source SMD2835

Warranty(Years) 5

Input Voltage(V) AC100-277V

Lamp Power(W) 20

Lamp Luminous Flux(lm) 2200

Lamp Luminous Efficiency(lm/w) 120

Color Temperature(CCT) Pure White

Working Temperature(℃) -25, 40

Working Lifetime(Hour) 50000

Lamp Body Material PC

IP Rating IP44

Certification CCC, CE, EMC, Energy Star, FCC, PSE, UL

Place of Origin Guangdong, China

Brand Name Alite LED

Model Number T8

Ballast bypass 4ft 4000k led t8 lamp 15 watt t8 led tube 1800 lumens

Product Description

Product Features:

The Ballast Compatible Plug & Play LED tube using patented electrical circuit,can be compatible with Rapid Start, Instant Start ,dimming electronic ballast ; Can be Double-end Power and no rewire to directly replaceconventional fluorescent; Compliant wit North America ,European and many countries' safety requirements.

Advantages:
1.Compatible with Rapid start, Instant start, dimming electronic ballasts etc., most of existing ballasts;
2.Direct replacement for traditional fluorescent tubes, no need to remove the starter & rewire;
3.Directly works well with line voltage 90-277VAC;
4.Work well with one pc or more tubes when driven by one ballast in a parallel circuit;
5.DLC,UL/cUL(#E343952),FCC,RoHS approved;
6.5 years warranty;

Prudoct Name	T8-4FT-20W-CPNA
Rated Power	20W
Input-Voltage	100~277VAC
Frequency	50/60HZ
Power Factor	>0.95
Socket	G13
Cover	Frosted
Color Temp	4000K	5000K
Lumens(typical)	1850LM	2050LM
CRI	≥82
SDCM	≤5.0
THD	<18%
Beam angle	180°

Model Number	Type	Length	Power Voltage	Lumen Typical	Base	CCT
T8-2FT-10W-CPNA	Electronic Ballast compatible	2FT	10W	1000-1200LM	G13	3000-6500K
T8-4FT-15W-CPNA		4FT	15W	1500-1850LM
T8-4FT-20W-CPNA		4FT	20W	2000-2200LM

Typical Compatible Ballasts (North America):

Installation of T8 plug and play type :

Packaging & Shipping

Packaging of ballast compatible LED tube:

Company Information

About UP-Alite LED
Alite LED is an experienced and professional indoor lighting LED products manufacturer with
ISO 9001:2008 since 2008,

Employee:

50 office employees - -370 first-line staff

Equipment:
- 5000 m² floor area
- 1000 m² warehouse- 550 m² conference room - 500 m² showroom for display
- 2000 m² "No dust "workshop. Full-automatic production facilities

Main Market: Australia, America, Europe.
Main Product: LED Panel light,LED T8 tube, LED PL Lamp, PAR light.
Certificate: DLC cUL&UL ES TUV CE ROHS ERP SAA PSE

FAQ

Q1: What is delivery time?
A1: Samples order: 7-9 days. bulk order 10-15 days according to detail requirements and
quantity.

Q2: What is the Warranty?Certificate?
A2: We always provide 3-5 years warranty. UL CUL DLC PSE SAA TUV CE ROHS.

Q3: What is the specific size of your tube?Dimmable?
A3: Its size is 600mm 900mm 1200mm 1500mm 2400mm.No,it is non-dimmable.

Q4.What payment terms do you provide?
A4:Paypal,Western union,T/T,L/C

Q5:Can we do OEM?
A5: Yes,you can,OEM sticker and OEM packing are available.

Q6: Can you do the UL multi-list with my company name ?How long it taks and what is the MOQ ?
A6: Yes,we can help you do the UL multi-list. It takes about 15-20 days.MOQ is 2000pcs.

Q7:what's your main market
A7: North America,Europe,Australia.

Q8:How to Contact Us?
A8:Send your Inquiry Details in the Below, Click "Send" Now! samples are waiting for you.
