Specifications
pe film shrink wrapping machine1. Packing form: 3*4,4*6
2. Packing speed: 10-12pcs/min
3. Total power: 21 KW
4. CE,ISO,BV,
pe film shrink wrapping machine
I. Main technical parameters
1. Packing form: 3×4,4×6 (or appointed packing spec
2. Packing speed: 10-12pcs/min
3. Applicable container shape:circular container,PE bottle,container outer diameter: dia40~110,height :60~340mm circular or quadrate container.
4. Total power charge:21kw/380v
5. Machine size:L×W×H=6500×3200×2100(mm)
6. Operating air pressure:0.6~0.8Mpa
7. Air consumption 0.5stere/min
8. Conveyor belt extreme breadth:304mm,
9. Conveyor height:according to fills Production line(Adjusting scope 200mm)
II. Main performance features
1.The shape is artistic,excellent, the frame is novel,unique, and repair is easy.
2.Electronic induction feeding film, with stable and smooth transfer speed, replacing film quickly.
3.Using isothermal sealing cuter, the seal intensity is 3 times above cooling and sealing cutter, the seal is even and the life is 80 times above cooling and sealing cutter.
4.3 sets of frequency control transport system, the transmission is precise and synchrony.
5.Adopting air circulation technology, the shrinkage chamber features rational structure, heat insulation, high precision for temperature control and better packing effects.
6. Disposition: CERMANY-SIEMENS,JAPAN-OMRON,TAIWAN-UNIQUE, etc advanced control component in the world, with well-equipped
III,Main parts
(Configuration subject to change without prior notice)
CB-6535 part name |
Technology |
Brand |
Isothermal sealing cutter |
TEFLON coat |
USA DUPONT |
PLC controller(core part) |
Japan |
OMRON |
Transducer |
Taiwan |
TAIAN |
All cylinder |
Original guide cylinder |
UNIQUC |
Motor protector |
Germany |
SIEMENS |
Regulator device |
Taiwan |
MINDMAN |
Approaches switch |
Korea |
AUT0NIC |
Contactor |
Germany |
SIEMENS |
Meshy belt |
USA |
DUPONT TEFLON FIBRE |
