Specifications
full automatic juice filling machine1. Capacity: 2500-25000 BPH
2. Suitable bottle: PET
3. Material: 100% sus304, 316
modern techniques for full automatic juice filling machine
Characteristics & advantage
1. It is designed more compact, more stable of ontrolling system, adopts with German FESTO, esay to operate and high automatically.
2. Using high accuracy and high speed filling level. Liquid level is more accurate without water loss, ensuring the quality of filling.
3. Capping heads use magnetic torque device, ensuring the capping effect and protect the bottle cap.
4. Using frequency conversion motor of German SEW, can be more convenient to adjust the capacity.
5. Controlling system has the liquid level control function, lack of cap detection alarm function, automatic alarm for card bottle function.
6. Using advanced touch screen control, can realize human-machine conservation.
Technical paraments
Model |
14-12-5 |
16-16-5 |
24-24-6 |
32-32-8 |
50-50-12 |
60-60-15 |
Capacity |
5000 (500ML) |
7000 (500ML) |
10000 (500ML) |
15000 (500ML) |
18000 (500ML) |
22000 (500ML) |
Suitable bottle |
Diameter50- 96, height 165-310 |
|||||
Air pressure |
0.7 Mpa |
|||||
Gas consumption |
0.8 m3/min |
|||||
Main motor power |
1.5 kw |
2.2 kw |
2.2 kw |
3 kw |
5.5 kw |
7.5 kw |
Total size |
2260*1610*2750 mm |
2850*2150*2750 mm |
3130*2400*2970 mm |
3430*2630*2970 mm |
5000*3770*2750 mm |
5300*3950*2970 mm |
Total weight |
2000 kg |
4200 kg |
5000 kg |
5500 kg |
7000 kg |
8500 kg |
Rinser part
1. All 304 stainless steel rinser heads, water spray style inject design, more save water consumption & more clean.
2. 304 stainless steel gripper with plastic pad, ensure minimum bottle crash during washing.
3. 304 stainless steel of washing pumps
Filler part
1. High precision filling nozzle, PLC variable signal control, ensure high filling precision & filling smoothly & steadily.
2. Isobar pressure filling nozzles which ensure minimum loss of CO2 from the drink
3. All 304 stainless steel contact parts & liquid tank, fine polish, easy to clean.
Capper part
1. Place & capping system, electromagnetic capping heads, with burden discharge function, make sure minimum bottle crash during capping.
2. No bottle no capping and automatic stop when lack of bottle.
Pre-service
1. Guiding customers to choose the most suitable machine and give our suggestion.
2. Provide the technical flow chart, machine photo, even machine vedio.
3. Specially designed a project for customer
4. Help customer design the workshop layout.
On-sale service
1. Tell customer about the production from time to time
2. Do preparation for customer checking at any time
3. Help customer clean goods.
After-sale service
1. Oversea install and training
2. Free maintenance and replacements of spare parts for free in 12 months.
3. Engineers available to service overseas.
4. Provide technical support.
Jiangsu Zhongyin Machinery Co.,Ltd (China-beverage) is focused on 5000-25000 BPH (500ml) production for liquid filling, like mineral water, pure water, carbonated drink, functional drink, tea, oil, condiments and others.
Our technical team and working team are all having over 10 years experience from the maturest company, like Newamaster.
Our suggestion
1. Thinking carefully what you want and your budget.
2. Find what you want on Alibaba,Google, Yahoo,Bing.
3. Choose some suppliers you think is good.
4. Email to these suppliers, tell them your details, like
--- What products you want to make?
--- What's your capacity? How many bottles in an hour?
--- What is the bottle? PET? PE? Glass? or Gallon?
--- What is your bottle size? 500ml? 1L? 2L or others?
--- Single machine or complete line?
5. According to supplier's contrast, choose two or three, some of your favourite supplier, and contact them, even do a visit.
6. You can ask them the qualification, like already coopeartion customer, exporting sales, producing situation etc.
