Basic equipment:
·Net capacity of grinding chamber 60L
·Volume of grinding media Approx151.2KG,on 70% fill percent
(L95 imported zirconium beads )
·Separating system Large-flow separating system
·Separating gap ≥0.1mm(adjust according to beads size)
·Cooling water flow Approx 5400 L/H
·Cooling water temperature 8-12℃
·Cooling water pressure 0.4Mpa
·Cooling water pipe Φ6mm
·Inlet pressure 0.12Mpa
·Outlet temperature 0-100℃(Adjustable)
·Feeding form Pump
·Dimensions(mm) 2230*1050mm*2200(L*W*H)
·Weight of the machine(kg) 3480
·Appearance color The color will be subject to the actual production
Longly standard is blue match grey
Feeding form
·Pump models ARO 1.5’’ Air-operated Diaphragm
Motor drive
.Voltage 415 V-50HZ
·Main motor power 75KW, IP55
·
Main drive Belt pulley,constant speed,linear speed could
not adjust by belt pulley
.Bearing NSK,imports from Japan
·Electrical accessories ShihLlin/Schneider
·Shaft Speed 1490rpm 13.32m/s(linear speed)
·Protection grade IP55
·Control system Frequency control(IP55)
.Protector Contact pressure induction protective device,the
host autoatically stop when high pressure in grinding chamber. Liquid level pressure induction protective device;Circulating pressure induction protective.
Mechanical seal
.Sealing form Dual –acting mechanical seal
(Alloy steel + silscon carbide)
·Sealing pressure 0.2-0.3Mpa
·
Seal ring O-ring anticorrosion Du Bangquan fluorine
sealing ring
·Seal ring material PTFE/Viton
·Sealing liquid Similar to the material,ensure no pollution material
5. High wear-resistant parts
.Inner chamber Alloy steel
.Peg Tungsten carbide
.Rotor Ceramic
·Separating material Large-flow separator,SUS304
