Company Profile:
Yuhuan Tino Imp&Exp Co., Ltd is complex of producer and trading company , mainly producing kinds of safety valves, T61M seriese for electric water heater, T611-614 for wall-hung boiler and central heating system, 61T1-61T2 is designed for pressure vessel such as solar water heater, any steam tank ,which need control temperature and pressure.And Automatic air vent including solar air vent, home appliance water pressure reducing valve. And other brass fitting.
Series 0315
Steam Safety Valves
Size: 3⁄4" (20mm)
Series 315 ASME rated Steam Safety Relief Valves provide high quality dependable low cost protection for any low pressure steam heating equipment operating up to 15psi. Available at lower settings, such as 8psi for pressure cooker and steam cleaning equipment requirements. Consult your local Watts agent for ratings at lower pressure settings.
Series 0315 features a bronze body and stainless steel spring. A top guided stem and non-stick PTFE® disc to metal seating ensures
positive shutoff. Capacity at 15psi is 375 lbs./hr.
Features
•High capacity
•Positive shut off
•Non-sticking PTFE®disc
•Seat located above drain
•NPT threaded male inlet x threaded female outlet(drain) connection
Models
L – Extended inlet shank to accommodate thick insulation SC – Satin chrome finish
Specifications
Steam Safety Relief Valve shall be installed on the boiler where noted on the plans. Valve shall be manufactured out of bronze with stainless steel spring, non-stick PTFE® disc, and metal seat. Valve shall have a maximum operating pressure of 15psi.
Materials
Body: Bronze
Spring: Stainless Steel
Disc: Non-stick PTFE®
Seating: Bronze
Pressure — Temperature
Capacity at 15psi is 375 lbs./hr.
