Features:
- Adopt world-famous components: AINAC pneumatic tool; Schneider sensor; Autonics switches; Victory touch screen PLC control system; Delta frequency invertor……
- Fully PLC automatic control (feeding, bottle sorting, heat-shrink & cooling) for accuracy and reliability.
- Sensor control and adjust the length of packing material to save cost.
- Advance helix wind circulation structure for energy-saving.
- Durable stainless steel structure with fully plastic coating.
Product |
Automatic Non-tray Heat-shrink Packaging Machine / shrink wrap packing machine |
|
Model |
WD-150A |
|
Packaging Dimension |
Main Machine |
1,180 X 1,080 X 2,370mm |
Shrinking Oven |
3,890 X 1,050 X 2,040mm |
|
Power Distribution Box |
1,250 X 780 X 1,100mm |
|
G.W. |
1.2 tons |
|
Input Power |
AC380V/50Hz 20KW |
|
Packing Speed |
8~15 packages per min (depend on package size) |
|
Shrink Time / Temperature |
0.5~1.5s / 150~260oC (Adjustable) |
|
Max Packing Size |
600 X 400 X 350mm |
|
Packing Material |
PE , PVC , POF |
|
Material Thickness |
0.03~0.15mm |
|
Application Scope:
Specially designed for high speed automatic bottling lines of juice, beer, mineral / pure water, milk, etc., this machine can pack plastic / glass bottle and paper box tightly. The finished package is weatherproof unlike paper carton, yet low cost.
Linear / vertical models with higher speed available. Please hurry and contact our sales engineer for your own packaging solution.
