XGF 24-24-8 Bottle Filling Machine(3-in-1) Liquid filling machine Composing:
1) Rinsing system: Rinsing gripper dial, separating water dial, water trough
2) Filling system: Liquid tank, filling valves, controlling rings
3) Capping system: Screwing capper, cap sorter, falling cap guide
XGF 24-24-8 PET Bottle Washing Filling Capping Machine General description:
XGF 24/24/8 Washing-Filling-Capping (Three-in-One) Unit made by our company is a new product which is researched and developed on the base of importing ,assimilating and absorbing the advanced technology of the same kind of domestic and foreign products, combining several-year-production experience of the company. The unit collects washing, filling and capping together. It is driven by a transmission motor. It has advantages, such as high automation level, compact structure, beautiful appearance, convenient and simple operation, safe and reliable and adjustable continuous production capacity and others. It is an ideal no-gas liquid filling production equipment in the country. It is mainly suitable for filling and capping of round or square polyester bottles. According to the demands of different specifications of users, it is only changed a little in design to meet the user’s demands.
Capacity Scale of Bottle: 350—2000ml;
Diameter Scale of Bottle: Dia50mm–Dia90mm;
Height Scale of Bottle:160mm-310mm;
Drink Kind: Mineral Water, Pure Water, Fruit Juice, Wine and other no-gas liquid.
XGF 24-24-8 WASHING-FILLING-CAPPING (THREE-IN-ONE) UNIT Main Technological Parameters
| MODEL | XGF 24-24-8 |
| Production Capacity | 8000-9000 bottles/h |
| Washing Head Quantity | 24 |
| Filling Valve Quantity | 24 |
| Capping Head Quantity | 8 |
| Filling Temperature | Normal temperature |
| Filling Type | Constant Pressure Filling |
| Main Motor Power | 3KW |
| Ordering-Cap Motor Power | 0.09KW |
| Cap Elevating Motor Power | 0.34KW |
| Washing Pump Power | 0.37KW |
| Liquid Inlet Pump Power | 0.55KW |
| Air Convey Motor | 1.1KW |
| Reflux Pump | 0.37KW |
| Consume Water | 1.8T/h ( Un-including drink water) |
| Control Type | PLC |
| Central Diameter of Filling Valve | Dia960mm |
| Central Diameter of Capping Machine | Dia320mm |
| Central Diameter of Washing Machine | Dia960mm |
| Dimension | 2950 X 2250X2300mm |
| Net Weight: | 4000kg |
After sales Service Terms: we provide one year limited warranty*1 and life long support service for all of our products.
During the warranty period, if any product purchased from our company malfunctions, we will provide necessary technical support, or even send engineers to solve the problem with the buyer providing proper accommodation, all the fees for transportation(the air tickets to you for economy class), insurance and medicines, and salary for our engineers*2 and 1 translater,the sallary based on USD60 per day.
