1. PRODUCT TECHNICAL PARAMETERS
Product Name |
Fixed Digital LCD Stroboscope |
Model |
DT316J |
Power Type |
Connected to main power through a plug |
Type |
Fixed |
Measurement Method |
No-cursor fixed length detection |
Working Voltage |
AC220V |
Total Power |
Less than 40W |
Working Frequency |
50-60HZ |
Environment Illumination |
Less than 10000 Lux |
Lamp Spec. |
Original German Hyman lamp, lifetime 1*108 |
Trigger Mode |
Internal and External Trigger |
Operation Interface |
Key button and rotary encoder |
Internal Flash Frequency Range |
60-20000 FPM/min. |
External Flash Frequency Range |
60-99999 FPM/min. |
External Mode Triggered by |
Omron Proximity Switch |
External Trigger Signal Range |
5-12V Pulse Signal( high level trigger) |
Size |
235mm*120mm*120mm |
Net Weight |
1.2kg |
2.WARRANTY
We offer 1 year warranty for our digital stroboscope lamp. If the strobe light is out of working order under proper usage per instructions manual within the warranty period, please contact us to obtain a merchandise return code and shipping instruction. Then, send it back at your shipping costs. After receiving your return item, it will take 7 days for evaluation and investigation. A brand new replacement unit will be sent to you at our shipping costs if it meets our warranty requirements.Porta
ble Strob
3. CERTIFICATE
We have obtained the quality management system certificate of ISO9001:2008 and CE certificate. Besides, our digital tachometer stroboscopes have passed EMC test and other domestic test.
4.EXHIBITION
In the past years, our company had presented in many domestic and abroad exhibitions and fairs, and have been recognized by lots of enterprises
.
5.Products used by Thailand customers.
