5 Gallon Bottle Washing Filling Capping Machine
US$ 3,500 - 3,580
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage
Driven Type:
Pneumatic
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
20 Liter Bottled Water Filling Machine PriceUS$ 3,500 - 3,580MOQ: 1 Set -
5 Gallon Bottle Washing Filling Capping MachineNegotiableMOQ: 1 Set
-
Automatic Mineral Water Bottle Sealing MachineUS$ 48,000 - 50,000MOQ: 1 Set
-
5 Gallon Water Machine Production LineNegotiableMOQ: 1 Set
-
5 Gallon Bottle Water Machine PriceNegotiableMOQ: 1 Set
Condition
New
Application
Beverage
Driven Type
Pneumatic
Automatic Grade
Automatic
Power
1750
Packaging Type
Other, export wooden case
Packaging Material
Plastic
Place of Origin
China
Brand Name
Kinglife
Model Number
XG-J/100(200BPH)
Specifications
Cylinder system :made in TaiwanNumber of bottle carrier / nozzles 2 bottle carrier,8 sets spraying nozzles
PLC system:DVP-32E
Automatic 5 gallon bottle washing filling capping machine: XG-J/100(200BPH)
| ITEMS | Model | XG-100/J(200BPH) |
| Washing part | Number of bottle carrier / nozzles | 2 bottle carrier,8 sets spraying nozzles |
| Number of rows for washing | 4 rows (each row 2 bottle carrier) | |
| Number of rinsing pump | 4 sets of Lingxiao pump BLC505 | |
| Rinsing stations 1st to 2ed row | Detergent washing | |
| Rinsing station 3rd row | Clean water washing | |
| Rinsing station of the 4th row | Ozone water washing | |
| Filling part | Number of filling pump | 2 sets of Lingxiao BLC755 |
| Filling nozzle system | 2 sets of SS304 type | |
| Cylinder system | 50*50 x 2, 50*525 x 1 Taiwan Airtac | |
| Pressure valves | 3 sets of 4V210-08 Taiwan Airtac | |
| Filters rugulators lubricators | AW-2000 Taiwan Airtac | |
| Pressure sensitive switch | YSNS-C110 Taiwan Airtac | |
| Capping part | Automatic caps tank/caps chute | 100pcs caps tank (manual caps dosing) |
| Numbers of the capping chuck | 2 sets of sticking type | |
| Controlling unit | PLC system | DVP-32ES Taiwan Zhongda |
| Signal relay system | 16 sets of MY2NJ-220AC Japan Omron | |
| SS304 electric-magnatic valve | ZCS-15L 12 pcs, ZCS-25L 2 pcs | |
| AC contactors | 9 sets of GMC-9 LG Korea | |
| Electric-creapage switch | C45N-32/4p France Merin gerin | |
| Speed gear motor | 2 sets of 0.75Kw pearl river motor | |
| Fuse jacket | 19 sets of RT-18-32 Shanghai APT | |
| Dimension | Machine size | 2950 x 780 x 1520mm |
| Weight | Gross weight | 335kgs |
PLC time controlled system by detergent cleaning,clean water cleaning,pure water cleaning Ozone water clean,the cleaning system is by pump controlled cleaning tank and the ejecting nozzles system on the bottle carrier system.2 bottles bottle carrier to the rinsing and filling mahcine,
After the inner bottle cleaning system, the bottles will come out of the bottle carrier by the automatic reverse turn-over system and being conveyed to the filling nozzles for filling.filling nozzles will be connected to each filling piping system by the filling water pump control.
