200Ton Vertical Injection Molding Machine for Rubber Product ( First-in, first-out)
Stationary four cylinders balancing vertical injection structure, hyperstatic injection force
Optimized shot feeding rod greatly reduces the rubber leakage and is convenient and fast for maintenance and rubber replacement
Innovative shot feeding tube constant temperature system plus ultrashort nozzle make every few remaining materials and minumum pressure loss
Specification under 500Ton adopts the international popular and davanced FIFO first-in first-out injection way
Totally enclosed safety shield and grating, higher equipment operation safety grade
Hot plate heating zone control makes teperature more even
Bigger table board design
More automatic functions may be selected
Model Number: TWL-200T
Clamping Force: 200Ton
Stroke: 500mm
Working Plate Size: 600*600mm
Diameter of cylinder: 350mm
Max. Plate Space: 550mm
Min. Mould Height: 60mm
Crane Travel: 200mm
Joe Travel: 200mm
Volume Injection: 2000cc
Injection Pressure: 220MPa
Screw Diameter: 45mm
Nozzle Aperture: 6mm
System Pressure: 21MPa
Horse Power: 15HP
Heater Power: 19KW
Total Power: 36KW
Gross Weight: 7200KG
Machine Size: 2700X1200X3600mm
