1.5mA power piezoresistive pressure sensor
- 1000 Piece / Pieces per Month
- XI'AN
- T/T Credit Card
Product Details
Place of Origin: | China | Brand Name: | HT | Model Number: | HT13V |
Product Description
Specifications
Measurement Range: 0~350KPa~60MpaPiezoresistive silicon sensing element
Constant voltage supply
Full 316L
Description
HT13V isolated pressure sensor, uses thick film to do compensation. Laser trimming ensures its reliability,have simple profile.
Feature
Multiple profile
Small construction
Full316LSS
Constant voltage supply
Application
Measurement pressure of gas and liquid
Industry process control
Electrical Data
Supply: 10VDC
Input Impedance: 6KΩ~20KΩ
Output Impedance: 2.5KΩ~6KΩ
Insulation Resistance:≥100MΩ/50VDC
Insulation Voltage:500VAC between the case and electrical connections will not cause damage
Medium Compatible: Liquids, gases which are compatible with 316LSS
Performance Specification
Parameter | Range:0~350 KPa ,700 KPa ,1 MPa ,2MPa,3.5MPa, 7MPa, 10MPa,20MPa,35MPa,60MPa | ||
Typical | Max. | Unit | |
Nonlinearity | ±0.15 | ±0.3 | %F.S |
Repeatability &Hysteresis | 0.05 | 0.1 | %F.S |
Zero Output | 0±1 | 0±2 | mV |
Span Output | 100±1 | 100±2 | mV |
Temperature Error- Zero | ±0.8 | ±2 | %F.S |
Temperature Error -Span | ±0.8 | ±2 | %F.S |
Proof Pressure | 3X Rated range or 100MPa, whichever is less | —— | |
Operating Temperature Range | -20~80 | °C | |
Compensated Temperature Range | 0~70 | °C | |
Storage Temperature Range | -40~125 | °C |
Note :Above parameter under condition:Supply: 10V Temperature: 25°C
