Help CenterPressure Sensor
Related Products
Specifications
Wide measurement range:0~10KPa~100MpaFull 316LSS, Titanium or Hastelloy diaphragm
Flush membrane configuratn
key word: water pressure sensor
Performance Specification
Parameters |
Range:0~10KPa,35KPa,0~70KPa,100KPa,200KPa,350KPa,700KPa,1000KPa,2000KPa,3500 KPa,7MPa,10MPa ,20MPa,35Mpa,60MPa,100MPa |
|||
Typical |
Max. |
Units |
||
Pressure Non-linearity |
±0.15 (0~2MPa) ±0.2 (3.5MPa~100MPa) |
±0.3 |
%F.S |
|
Pressure Repeatability and Hysteresis |
0.02 |
0.05 |
%F.S |
|
Zero Output |
0±1 |
0±2 |
mV |
|
Span Output |
≤20KPa |
50±10 |
50±30 |
mV |
≥35KPa |
100±10 |
100±30 |
mV |
|
Temperature Error-Zero |
≤20KPa |
±1 |
±2 |
%F.S |
≥35KPa |
±0.5 |
±1 |
%F.S |
|
Temperature Error-Span |
≤20KPa |
±1 |
±2 |
%F.S |
≥35KPa |
±0.5 |
±1 |
%F.S |
|
Proof Pressure |
3X Rated range or 120MPa,whichever is less |
------ |
||
Operating Temperature Range |
-20~80 |
°C |
||
Compensated Temperature Range |
0~70, 0~50(Range≤20KPa) |
°C |
||
Storage Temperature Range |
-40~125 |
°C |
||
Note :Above parameter under condition:Supply: 1.5mA Temperature:25°C
