Full Automatic Barrel Filling Production Line
Filling production line
This Barreled filling line specially produces 5 gallons bottled drinking water,whose types(b/h)are:300type,450 type
It integrates bottle washer, filler and sealer into one unit ,in order to achieve the purpose of multiple injections of washing and sterilizing by means of liquid washing and leaching are used in bottle washer, Washing solution can boused circularly .
The sealer can seal bottle caps automatically. This line equips with water spraying device to sterilize caps of bottles in order to ensure those caps are aseptic and healthy ,also this line can automatically carry out bottle feeding washing, sterilizing, filling capping, counting and products discharging .
It is a new kind of barreled water auto-producting line ,which integrates mechanism, electricity and pneumatics technologies together.
Trademark: RELIABLE
Main Technical parameters | |||||||
Model |
QGF-100 |
QGF-300 |
QGF-450 |
QGF-600 |
QGF-900 |
QGF-1200 |
QGF-2000 |
Filling heads |
1 |
2 |
3 |
4 |
8 |
12 |
16 |
Volume(L) |
18.9 |
18.9 |
18.9 |
18.9 |
18.9 |
18.9 |
18.9 |
Barrel size(mm) |
φ270×490 |
φ270×490 |
φ270×490 |
φ270×490 |
φ270×490 |
φ270×490 |
φ270×490 |
Capacity(B/n) |
100-120 |
200-240 |
300-400 |
600 |
900 |
1200 |
2000 |
Gas pressure(mpa) |
0.4-0.6 |
0.4-0.6 |
0.6 |
0.6 |
0.6 |
0.6 |
0.6 |
Gas consumption |
0.37 |
0.6 |
0.6 |
1.2 |
2.2 |
3 |
4.5 |
Motor power(Kw) |
1.75 |
3.22 |
4.8 |
8.5 |
8.5 |
8.5 |
8.5 |
Rated voltage(V) |
380V/50Hz |
380V/50Hz |
380V/50Hz |
380V/50Hz |
380V/50Hz |
380V/50Hz |
380V/50Hz |
Outline dimension(mm) |
3790×650 |
3550×800 |
3550×1200 |
3650×1500 |
2200×1860 |
2560×2350 |
3100×2800 |
Beijing yuanxiang vegetable foods machine factory, which is a specialized research and production equipment enterprise for fruit and vegetable processing and deep processing production of various agricultural and sideline products. We are engaged in these industry from 1983.The main products are: potato peeling machine, fruit and vegetable washing machine, vegetable cutting machine, fresh vegetable processing line, vegetable salad production line; dehydrated vegetables production line, fruit and vegetable can production line; IQF vegetable production line; dried apricots production line, potato chips production line; French fries production line and so on.Our sell market is throughout China and other 30 more foreign countries like Thailand, Singapore,Costa Rica, Kenya, Russia, Uzbekistan, New Zealand, South Africa, Mongolia, India, Afghanistan, Uganda, Egypt, etc.
