Specifications
1.Name: Pex-al- pex pipe2.material: Korea LG brand
3.Laser or overlap
4.Work pressure: 10 bar
superiority:
1.Adopt butt-jointed seam technology. Make the body of the pipe more
circular. Since it will endure more pressure.
2.Completely 100% new materias ensure it more healthy than the pipe made
up of reclaimed plastic.
3.Heat-resistance characteristic capacitate the pipe work normally between
-40deg to 95deg.
4.Pealike color and satin felling impress you deeply.
5.Super long work life of our pex pipe for 50years ensured by PICC.
6.we had been PEX-AL-PEX pipe manufacturer for over 10years. we are good
at this.
7.past ISO9001 authentication. and had been got CEcertification.
composite pipe s Specifications:
|
DIMENSION (mm) |
OUTER DIAMETER (mm) |
INNER DIAMETER (mm) |
WALL THICKNESS (mm) |
OPERATION TEMPERATURE (mm) |
16×2.0 |
16.0 |
12.0 |
2.0 |
-45~95 |
16×2.25 |
16.0 |
11.5 |
2.25 |
-45~95 |
18×2.0 |
18.0 |
14.0 |
2.0 |
-45~95 |
20×2.0 |
20.0 |
16.0 |
2.0 |
-45~95 |
20×2.25 |
20.0 |
15.5 |
2.25 |
-45~95 |
20×2.5 |
20.0 |
15.0 |
2.5 |
-45~95 |
22×2.0 |
22.0 |
18.0 |
2.0 |
-45~95 |
25×2.5 |
25.0 |
20.0 |
2.5 |
-45~95 |
26×3.0 |
26.0 |
20.0 |
3.0 |
-45~95 |
32×3.0 |
32.0 |
26.0 |
3.0 |
-45~95 |
Color:
White, Orange, Blue, Yellow can be changed according to customer's requirement
Characteristics:
1.At normal temperature, it does not dissolve in any known solutions and is resistant
against various kinds of acid, alkali and salt.
2 Heat preservation: low thermal conductivity which is only 1/1500 of brass pipe,1/250 of steel pipe.
3.Non-toxic; No heavy metal additive,wouldnt be covered with dirt or contaminated by bacterium.
4.Corrosion resistance: resiste chemical matters or electron chemical corrosion.
5.Lower installation costs: Light weight and easy to installation.
6.High flow capacity: smooth inner walls reduce pressure loss and increase flow speed.
7.Long usage time: at least 50 years under the normal conditions.
8 Recycled and environment friendly.
Technicial:
1,working temperature:-45°c to 95°c.
2,working pressure: 1.0MPA.
3,working medium:Water,Gas.
4,Colour:any colour we can produce.
5,Size:16mm,18mm,20mm,25mm,26mm,32mm
6,Material:HDPE LG,5000S,etc.
7,package:Three layers film-wrapped,standard export carton,Bag.
package:150ms/roll, pipeline are packed in plastic bags
payment:T/T at sight, 30% in advance.
delivery time:
20" container will be delivered in a week;
40" container will be delivered in 20 days.
MOQ:20" container, or 1000ps per item.
