Medium Duty long span storage racking
USD $1.2 - $1.6
/ Set
10 Sets(Min.Order)
- 10000 Set / Sets per Month
- Tianjin
- T/T Credit Card
You May Like
- Radio Shuttle Racking With Pallet
- Drive in Rack Warehouse Storage
- Light Duty Warehouse Storage Rack Shelf Garage Shelves
- Pallet warehouse pallet forklift pallet
- American Type Industrial Warehouse Storage Heavy Duty Teardrop Pallet Racking
- 1200X1000 mm Powder Coating Storage Logistic Metal Steel Pallet for Transportation
Product Details
Place of Origin: | Hebei, China | Brand Name: | HEGERLS | Model Number: | HGLS-BR--05 |
Type: | Other, Pallet Rack, Steel Plate Stacking Racks | Scale: | Heavy Duty | Capacity: | MANY |
Product Description
Medium Duty Storage Rack
This Medium Duty Storage Rack is perfect for handling light loads, with a load capacity of 200-800kg per level. It is durable and smart in appearance. Assembly is easy with boltless connection. The metal decking levels are adjustable at steps of 50mm.
Features:
- Material: stainless steel
- Shelving Structure: upright, metal deck, shelf clip, foot plate, main frame, sur-frame and other accessory
Deck Type: Multiple deck types are available.
- Height of Each Layer: it can be adjusted by pitch 50mm freely
- Levels: it is optional(1 to 4 layers)
- Max Load Capacity: 200 to 800 kg/layer;
- Size: different size available
- Surface Treatment: static powder coating
- Color: RAL color system
- Process: all the accessories of this Medium Duty Storage Rack are processed by polishing, acid cleaning, phosphating, automatic static sprayed, baking and so on.
- Installation &Disassembling:Modular design makes assembling and Disassembling easy
- Usage: this Medium Duty Storage Rack is often used in warehouse, grocers, book stores, library, garage and other public fields
Specification of this Medium Duty Storage Rack :
Model | Specification (Main Frame) | Specification (Optional Frame) | No.of Levels | Load Capacity per Level |
MS50-50-1250 | 1250Lx600Dx2000H | 1200Lx600Dx2000H | 4 | 350kg |
MS50-50-2000 | 2000Lx600Dx2000H | 1950Lx600Dx2000H | 4 | 200kg |
MS50-60-1250 | 1250Lx600Dx2000H | 1200Lx600Dx2000H | 4 | 500kg |
MS50-60-2000 | 2000Lx600Dx2000H | 1950Lx600Dx2000H | 4 | 300kg |
MS50-70-1250 | 1250Lx600Dx2000H | 1200Lx600Dx2000H | 4 | 650kg |
MS50-70-2000 | 2000Lx600Dx2000H | 1950Lx600Dx2000H | 4 | 400kg |
MS50-80-1250 | 1250Lx600Dx2000H | 1200Lx600Dx2000H | 4 | 800kg |
MS50-80-2000 | 2000Lx600Dx2000H | 1950Lx600Dx2000H | 4 | 500kg |
