Crawler and Trailer available! HF-360 Trailer Type Screw Pile Drill Machine Price
USD $30,000 - $40,000
/ Set
1 Set(Min.Order)
- 50 Set / Sets per Month
- Usually Qingdao other ports also available
- T/T
You May Like
-
China Xy-200 Water Well Drill Rig Machine for Soil and Rock Drilling
-
100 Meters Xy-1A Water Well Drilling Rig Machine Equipment
-
HY-50H Small Domestic Hydraulic Water Well Drilling Rig of China
-
50m Depth Core Drilling Rig Portable Diamond in Mountain
-
TSP core bit, BQ NQ HQ PQ core drill bits, HWL, wireline core barrels, diamond coring bits, hard formation, deep hole rock core recovery
-
1.5M 3M inner tube assembly, wireline core barrels, head assembly, impregnated diamond drilling, hard formation coring, deep hole rock core recovery
Product Details
| Condition: | New | Type: | Other, Auger drill | Power Type: | Electric |
| Place of Origin: | Henan, China | Brand Name: | Hanfa | Model Number: | HF-360 |
| Usage: | Other, pile | Voltage: | customized | Power(W): | 50kw |
| Dimension(L*W*H): | 11.5m x 2.1m x 13.6m | Weight: | 8.5tons | Certification: | CE |
| Warranty: | 1year for main machine | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Crawler and Trailer available! HF-360 Trailer Type Screw Pile Drill Machine Price
Specifications
Model | HF-360 | |||
Hole diameter | 400mm | 600mm | ||
Drilling depth | 19m | 18m | ||
Revolution angle° | 360° | |||
Overall dimension | Operating mode | 11.5m×2.1m×13.6m | ||
Weight | 8.4t | 8.6t | ||
Wheel | 8 pcs | 8 pcs | ||
Generator power | 50kw | 50kw | ||
Hoist power | 3/11t/kw | 3/11t/kw | ||
Hydraulic oil pump power | 11kw | 11kw | ||
Travel power | 24kw | 24kw | ||
Oil pump flow | 32ml/r | 32ml/r | ||
Oil pump pressure | 16mpa | 16mpa | ||
Travel type | Short distance travel by electric and hydraulic; long distance by diesel | |||
