Specifications
water well drill rigs for sale1. crawler type, easy to move and durable
2. powerful, high efficiency
water well drill rigs for sale
Powerful & Durable HF300Y Crawler Water Well Drilling Rig
1,HF300Y drilling rig have the character of light,high efficiency, multi-function. According to different conditions,it uses air,foam or slurry to rotate and drill.
2,Application:it is widely used in industrial and agriculture water project,drill water well,testing well and other exploration borehole. in particular, in drilling hole for geothermal heating,it can also meet the engineering basis for reinforcement, loose gravel drilling rock formation connected with a variety of engineering requirements
3,Console and platform combination, easy to operate, with platform wide enough to enable the operator and the assistant to leave the mud appropriate height operations, folding walking platform, the control system to focus on the operation platform, easy to operate.
4,Hydraulic driving force for car engines, according to the impact of perforation size and the selected configuration corresponding compressor can greatly reduce the energy consumption and construction investment costs.
5,Steel crawler chassis and hydraulic jacks and level of instrument use; it can guarantee its complex environment in any rugged and accurate under normal perforation operation.
6,Rotating power head has two low-speed high torque hydraulic motor drive, can ensure strong torque output. In the main volume state, turret, and the centering device put to one side, away from the centerline, to enhance the discharge rod or casing.
Technical parameter;
Bore diameter 115-320mm
Bore depth 320m
Work pressure 1.05-3.0Mpa
Air consumption 16-30m3/min
Drill rod length 3m
Drill rod diameter 89mm
dimension 6300*2320*2780
Climb ability 30degree
Walking speed 2.5km/h
Total weight 11.5T
Feed system Axial pressure 57000N
Hoist force 80000N
Rotation torque 5200NM
Rotation speed 130r/min
