HFKP2500 Full Hydraulic Pressure Engineering Mode Drilling Machine

US$ 150,000 - 300,000 MOQ: 1 Set

Key Specifications

Place of Origin:

China

Brand Name:

Model Number:

HFKP2500

Zhengzhou Hanfa Prospecting Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Tianjin Qingdao port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name HF

Model Number HFKP2500

After-sales Service Provided Engineers available to service machinery overseas

Specifications

Drilling Machine
1. max depth:120m
2. diameter:2.5m
3. full hydraulic

Drilling Machine

HFKP2500 Full Hydraulic Pressure Engineering Mode Drilling Machine

Product description:

HFKP2500 is a species of full hydraulic pressure rotating plate-drilling machine develped by our company newly. This drill adopts full hydraulic

pressure drive, constant power variable loop, wheel cylinder and electrohydraulic

multiple operation. The drill can adjust Torque according to stratum situation and

reduce pressure to drill automatically.

The engineering drilling machine of HFKP2500 type is double layers bottom plate,

and the drives through hydraulic pressure. The upper plate can move on the lower

plate, and the drill power sets up guide back leaning device, which leans back under

the action of oil cylinder. The lower plate can put the drilling tool within 2.5meters into

well hole without moving. It is convinient and reliable, and ensures construction quality.

The motion of lower plate adopts steel form,which moves conviniently, securely and

stably.

Drilling Diameter(m)	2.5m
Drilling Depth(m)	120m
Max.Torque(kN.m)	80
Max. Rotary Speed(r/min)	24
Main Machine Power(kw)	45X2
Main Hoist Single Rope Pull(kN)	60
Assistant Hoist Single Rope Pull(kN)	15
Main Machine Weight(T)	21
Grief Joint(mm)	273×273
Passive Joint(mm)	245×20
