Good Quality High Efficiency ~ Cnc Hss Drill Bits & HF Drill Bit

Good Quality High Efficiency ~ Cnc Hss Drill Bits & HF Drill Bit thumbnail-1
Good Quality High Efficiency ~ Cnc Hss Drill Bits & HF Drill Bit photo-1
US$ 1,800 - 2,200 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
HF brand PDC drill bits
Model Number:
pdc drill bits
Contact Supplier Request Quote Chat Now
Zhengzhou Hanfa Imp & Exp Trading Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Zhengzhou/Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name HF brand PDC drill bits
Model Number pdc drill bits
Type Other, PDC drill bits
Material High Carbon Steel
Use Well Drilling

Specifications

cnc hss drill bits
1.best quality for 6"~17 1/2"
2.high quality,best price
4.number of blade :4,5,6,7,8,9

Good quality High efficiency ~ cnc hss drill bits





diamond hq core drill bits

Specifications



Diamond core bits
1. High efficiency, long use life, low price
2. Application: concrete, granite, marble, refractory materials



Specialisted in producing varies kinds of diamond core bits in different international standard size for soft, medieum to hard rock formations.



Including impregnated diamond core bit, surface-set diamond bit, reaming shells, impregnated diamond casing bit, casing shoe bit, TC core bit, TC casing bit, diamond reaming shell, corelifter, corelifter case, diamond sub-adapters,  hoist plugs, tap, etc.





With ISO certificate & quality control.



The impregnated diamond bits are the most commonly useful bits in the mineral exploration industry, as they have the widest range of application. The carefully selected grades of high quality synthetic diamond are distributed in the depth of impregnated bit's matrix series. The matrix layer of the ZM contains a uniform distribution of these crystals that are embedded in a powdered metal bond.

The matrix of our impregnated bits is designed to expose new diamonds to the bits' cutting face as wear occurs. Fast penetration rate is maintained as a result of this action.

Our impregnated bits are manufactured to give optimum penetration rates and bit life, which is required to keep the cost of diamond drilling to a minimum.

The optimum diamond size, concentration and matrix type are dependent on the hardness and abrasiveness of the formation to be drilled.

Size Available:
"Q" series: AQ, BQ, NQ, HQ, PQ/AQTK, BQTK, BQ3, NQ2, NQ3, NQTT, HQ3, HQTT, PQ3, PQTT
T2 series: T2 46, T2 56, T2 66, T2 76, T2 86, T2 101
T6 series: T6 76, T6 86, T6 101, T6 116, T6 131, T6 146, T6S 101, T6S 116
T series: T36, T46, T56, T66, T76, T86
Z series: Z46, Z56, Z66, Z76, Z86, Z101, Z116, Z131, Z146
B series: B36, B46, B56, B66, B76, B86, B101, B116, B131, B146
WF series: HWF, PWF, SWF, UWF, ZWF
WT series: RWT, EWT, AWT, BWT, NWT, HWT
WM series: EWM, AWM, BWM, NWM, HWM
WG series: EWG, AWG, BWG, NWG, HWG



Others: NMLC, HMLC, LTK48, LTK60, BGM, NGM, ADBG, TBW, TNW, ATW, BTW, NTW, NXD3, AX, NX, NXC, AXT, T6H, 4 9/16, NWD4, 412F, SK6L146, TT46, TB56, TS116, CHD101.







 Good quality High efficiency ~ cnc hss drill bits & HF drill bit



Good quality High efficiency ~ cnc hss drill bits & HF drill bit



Good quality High efficiency ~ cnc hss drill bits & HF drill bit

2.details:



Bit type

Main bit size(mm)

Rock coefficient

PDC core drill bit

Single pipe

75/54.5  94/74  113/89  113/109  153/129

1-18

Two-pipes

75/54.5  94/68

PDC center drill bit

Concave 3 wing bit

60  75  94  113  133

1-18

Arc pillar



60  75  94  113  133

4-18

Many wing scraper

60  75  94  113  133  133  153  173  190  215

1-6

PDC Indexable drill bit

153/94   153/113  190/153   190/113

1-18







Model

118,152,215.9,244,311,445

Type

all kinds and size PDC bits

Applicable

water well, oil field, construction, geothermal, directional boring, and underground foundation work

Formation

sticky, soft, medium hard, hard formation

blade

4,5,6,7,8,9

Packing

wooden box

Payment Term

T/T

MOQ

1 Piece

Supply Ability

1000 Pieces/month

Delivery Time

within 7-15 work days



 Good quality High efficiency ~ cnc hss drill bits & HF drill bit





FAQ(Frequently Asked Questions)



1. How to order the products?
Answer:
Send the inquiry with detail item description or with Model number.
If there is no packing demand we take it as sea-way packing.
If possible please attach one reference picture to avoid any misunderstanding or any links from our website for we get a better understanding.

2. About lead time and shipping time?
Answer :
The lead time depend on quantity of order. Usually shipped by sea, small order or urgent order we can send you by air after received your agreement.
According the distance from china to your port, usually from China to European about 25 days. To West of American 20 days.

3.Can I expect a quality products?
 Answer :
Yes. All our activities are accredited to ISO 9001:2008 and API, both in products and services, at the same time, mature production technology ensuring the quality satisfy international request.
