Heat Pump Water Heater
US$ 898 - 1,122
MOQ: 2 Pieces
Key Specifications
Get Latest Price
Type:
Air Source Heat Pump
Installation:
Freestanding
Storage / Tankless:
Storage
Payment & Shipping
Payment Methods:
Port of Shipment:
Foshan Guangzhou or Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Type
Air Source Heat Pump
Installation
Freestanding
Storage / Tankless
Storage
Housing Material
Other, Metal or stainless steel
Use
Bathroom
Certification
CB, CE, EMC, Other, SASO, CB, CE, EMC, RoHS, SASO, CCC
Place of Origin
Guangdong, China
Brand Name
DIBETTER or OEM brand
Model Number
DBT-3.5I-300
Specifications
1. Integrated&compact design,nice outlook and easy installation2. High COP as 4.0,saving operation cost
| Warranty: 24 months guarantee for the whole unit. | ||||||||||
| Features: | ||||||||||
| 1.Safety:water and electric separately. | ||||||||||
| 2.Simple installation:Compact design(Main unit and water tank),DIY installation is available to saving costs! | ||||||||||
| 3.Conveninet:Intelligent remote controller,with simple key operation.Displays error code when having problem,easy for maintenance. | ||||||||||
| 4.Multiple protections for the whole heat pump, guaranteeing safe operation. | ||||||||||
| 5.World famous brand compressor,4-way valve,motor,PCB,heat exchanger used to ensure top quality and high efficiency. | ||||||||||
| 6. All weather operation:stable operation without being influenced by weather. | ||||||||||
| 7.Metal case and stainless steel case are available,R22,R407C,R410a,R417A,R134A are for optional. | ||||||||||
| 8.Metal case water tank with powder coating or stainless steel case are available. | ||||||||||
| 9. Quiet:Special design for motor and fan to decrease noise, no disturbance to owners and neighbours. |
| Air to water heat pump(All In One type) | |||
| Parameters | Model | DBT | 3.5I-300 |
| Rated Heating capacity | kW | 3.5 | |
| Rated hot water capacity | L/H | 120 | |
| Rated power input | kW | 1.06 | |
| COP | W/W | 3.21 | |
| Rated operating current | A | 4.9 | |
| Power supply | 220V/1PH/50Hz | ||
| Rated output water temperature | °C | 55 | |
| Maximum output water temperature | °C | 60 | |
| Compressor | Type | High-efficiency & Low-noise Totally Enclosed Rotary | |
| Water side heat exchanger | Type | High-efficiency interior screw coil | |
| Water Tank Volume | L | 300 | |
| Gas inlet | mm | 6.35 | |
| Gas outlet | mm | 9.52 | |
| Air side heat exchanger | Type | Hilicl fin Hydrophilic aluminum foil exchanger | |
| Fan Type | Low-noise Wide-blade Axial Fan | ||
| Fan Quantity | 1 | ||
| Fan Power input | 50 | ||
| Refrigerant | Type | R22&R407C&R410A | |
| Unit noise level | dB(A) | 47 | |
| Working temp. range | °C | ||
| Water inlet & outlet | G3/4" | ||
| Dimensions | Unit | mm | 680 x 1820 |
| Package | 695 x 695 x 1920 | ||
| Weight | Kg | 95 | |
| Note: | |||
| 1.Rated heating conditions: ambient temperature DB20°C WB15°C,Initial/Final water temperature: 15°C/55°C | |||
| 2.The above designs and specifications might be changed without prior notice for product improvement | |||
